System And Components
2T-3783 GAUGE GP-CLUSTER -CABS/N 9XG1-UP
Group No: 2T-3783 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W3306 | 1 GAUGE GP-AIR PRESSURE (AIR TANK) | 1 | |
| 4B2049 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 2T3302 | 2 HARNESS AS-PANEL (GAUGES) | 1 | |
| 2T3758 | 3 PLATE AS | 1 | |
| 2250282 | 4 TACHOMETER AS | 1 | |
| 3L8187 | LOCKWASHER | 4 | |
| 4B5324 | WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 6V8368 | NUT (6-32-THD) | 4 | |
| 6V8377 | NUT (8-32-THD) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 3E3763 | 5 SPEEDOMETER AS | 1 | |
| 3E7240 | 6 INDICATOR-OIL TEMPERATURE (24-VOLT)(TORQUE CONVERTER) | 1 | |
| 4W0483 | 8 GAUGE GP-COOLANT TEMPERATURE (24-VOLT) | 1 | |
| 9X2042 | 10 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 9X3496 | 11 GAUGE GP-FUEL LEVEL | 1 | |
| 6V8368 | NUT (6-32-THD) | 3 | |
| 6V3507 | SEAL-RECTANGULAR | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 4B5324 | WASHER (3.9X9.6X1.2-MM THK) | 3 | |
| 4B2043 | NUT (8-32-THD) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 3S2093 | 14 STRAP-CABLE | 1 | |
| 5P4115 | 15 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 6D4246 | 16 CLIP (LOOP) | 1 | |
| 7X2058 | 17 LAMP (24-VOLT)(SPEEDOMETER) | 6 | |
| 9W2111 | 18 LAMP (24-VOLT)(ELECTRONIC MONITORING SYSTEM) | 1 | |
| 2T3759 | 19 FILM (DASH)(GAUGES) | 1 |
