System And Components
433-3465 BRAKE GP-SERVICES/N 2T91-UP
Group No: 433-3465
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9F2167 | 1 SCREW-PURGE (3/8-24X1.164-IN) | 1 | |
| 9M2076 | 2 RING-SNAP | 1 | |
| 1058724 | 3 HUB | 1 | |
| 1102446 | 4 ADAPTER | 1 | |
| 1186606 | 5 PLATE-OUTER | 3 | |
| 1730554 | 6 PIN (BRAKE DISC WEAR INDICATOR) | 1 | |
| 1730555 | 7 DOWEL-HOLLOW | 1 | |
| 1931152 | 8 HOUSING | 1 | |
| 1953722 | 9 PLATE-OUTER | 2 | |
| 2010737 | 10 DISC-FRICTION (EXTENDED LIFE) | 4 | |
| 3818291 | 11 PISTON | 1 | |
| 0966901 | 12 RING-RETAINING | 1 | |
| 1516250 | 13 SEAL-D-RING | 1 | |
| 1516251 | 14 SEAL-D-RING | 1 | |
| 3H7654 | 15 WASHER-HARD (13.5X22.5X3-MM THK) | 3 | |
| 3K0360 | 16 SEAL-O-RING | 1 | |
| 5P8119 | 17 SEAL-O-RING | 1 | |
| 6M9155 | 18 PIN | 4 | |
| 1628284 | 19 BOLT (M12X1.75X60-MM) | 3 | |
| 7V8346 | 20 SPRING-GUIDE | 4 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8V3609 | 22 SPRING-RETRACTOR | 4 |
