System And Components
133-2017 SUSPENSION GP-SEATS/N 4YR1-UP
Group No: 133-2017
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4J8394 | 1 SPRING | 1 | |
| 1551695 | 2 ARM AS-SCISSORS | 1 | |
| 1179166 | 3 CLIP | 26 | |
| 5R7545 | 4 TUBE-NYLON | ||
| 1042211 | 5 HOUSING AS | 1 | |
| 1042213 | 6 HOUSING AS (LOWER) | 1 | |
| 1068481 | 7 PLATE-SLIDE | 1 | |
| 1611233 | 8 PLATE AS-SHOCK | 1 | |
| 4L6454 | 9 BOLT (3/8-16X1-IN) | 6 | |
| 5S7349 | 10 BOLT (1/4-20X0.5-IN) | 4 | |
| 5S7383 | 11 BOLT (3/8-16X1.75-IN) | 2 | |
| 1387517 | 12 STRAP AS (SUSPENSION SEAT) | 2 | |
| 5P2566 | 13 BOLT (1/2-13X1.5-IN) | 2 | |
| 5M3062 | 14 BOLT (3/8-16X0.75-IN) | 1 | |
| 1387508 | 15 BOOT | 1 | |
| 1068601 | 16 PLATE-BASE | 1 | |
| 1387512 | 17 BUSHING | 2 | |
| 1339680 | 18 PLATE AS | 1 | |
| 1387513 | 19 SPRING | 1 | |
| 1339674 | 20 HANDLE AS | 1 | |
| 1068581 | 21 HANDLE-SLIDER | 1 | |
| 1068594 | 22 FRAME-UPPER | 1 | |
| 6P6256 | 23 RETAINER-SPRING | 1 | |
| 5S2671 | 24 BOLT (10-24X0.5-IN) | 2 | |
| 1387515 | 25 PIN | 1 | |
| 1439752 | 26 SPACER (907X27X14.3-MM THK) | 2 | |
| 1387516 | 27 WASHER (9.65X25.4X1.59-MM THK) | 1 | |
| 7M9910 | 28 SCREW-MACHINE (10-24X1-IN) | 1 | |
| 1339675 | 29 COUPLING | 1 | |
| 1068583 | 30 BRACKET AS | 1 | |
| 8T9380 | 31 BOLT (7/16-14X1-IN) | 4 | |
| 0100744 | 32 SCREW-MACHINE (6-32X1.25-IN) | 1 | |
| 8T7566 | 33 PIN-SPRING | 11 | |
| 6H3956 | 34 PIN | 1 | |
| 1611236 | 35 BUMPER | 1 | |
| 1448296 | 36 FITTING | 1 | |
| 1448298 | 37 FITTING-BULKHEAD | 1 | |
| 1387514 | 38 VALVE AS | 1 | |
| 1448296 | 39 FITTING | 1 | |
| 1448297 | 40 FITTING-STRAIGHT | 1 | |
| 4B2047 | 41 NUT (10-24-THD) | 2 | |
| 1611234 | 42 BLOCK | 2 | |
| 1024552 | 43 SHAFT AS | 2 | |
| 1607767 | 44 WASHER (3.68X12.57X0.51-MM THK) | 6 | |
| 1748173 | 45 WASHER | 6 | |
| 7X0562 | 46 WASHER-HARD (13.5X19X0.8-MM THK) | 1 | |
| 1070092 | KIT-AIR SPRING | 1 | |
| 1434803 | KIT-SHOCK ABSORBER | 1 | |
| 1494745 | KIT-SLIDER BLOCK (SUSPENSION SEAT) | 1 | |
| 1490732 | KIT-ROLLER | 1 |
