System And Components
415-6360 WHEEL & FINAL DRIVE GPS/N 2L61-UP
Group No: 415-6360 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D0604 | 1 BUTTON | 1 | |
| 2L3650 | 2 PIN-SPRING | 1 | |
| 2V5715 | 3 BUSHING-TERMINAL | 1 | |
| 2V7092 | 4 PLATE-RETAINER | 1 | |
| 2V7390 | 5 SHIM PACK (INCLUDES 15-SHIMS) | 1 | |
| 4E0072 | 6 WASHER-THRUST | 6 | |
| 4K6801 | 7 RING-LOCK | 3 | |
| 4V8538 | 8 GEAR-RING (64-TEETH) | 1 | |
| 4V8541 | 9 CARRIER AS | 1 | |
| 2L3650 | PIN-SPRING | 1 | |
| 5M0578 | 10 BEARING AS-ROLLER | 6 | |
| 1A1135 | 11 BOLT (5/8-11X2-IN) | 15 | |
| 9G5315 | 12 SEAL GP-DUO-CONE | 1 | |
| 2M0344 | RING-SEALING | 2 | |
| 1384805 | 13 SPINDLE | 1 | |
| 1384811 | 14 COVER AS | 1 | |
| 2D0604 | BUTTON | 1 | |
| 1471740 | 15 GEAR (23-TEETH) | 3 | |
| 1618150 | 16 CONE-BEARING | 1 | |
| 1618151 | 17 CUP-BEARING | 1 | |
| 1618152 | 18 CONE-BEARING | 1 | |
| 1618153 | 19 CUP-BEARING | 1 | |
| 1757528 | 20 HUB | 1 | |
| 1903594 | 21 SHAFT-PLANETARY | 3 | |
| 2160227 | 22 RETAINER | 1 | |
| 3851780 | 23 WHEEL | 1 | |
| 0S1585 | 24 BOLT (1/2-13X1.5-IN) | 6 | |
| 1654929 | 25 PLUG AS-MAGNETIC (DIFFERENTIAL) | 1 | |
| 5P4484 | PLUG-MAGNETIC (DIFFERENTIAL) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1J2176 | 26 SEAL-O-RING | 1 | |
| 3217848 | 27 STUD-WHEEL | 19 | |
| 5H2767 | 28 SEAL-O-RING | 1 | |
| 5H3252 | 29 SEAL-O-RING | 1 | |
| 5P8245 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P8247 | 31 WASHER-HARD (17X32X3.5-MM THK) | 15 | |
| 5P9928 | 32 RING-RETAINING | 1 | |
| 7K6058 | 33 BOLT-12 POINT HEAD (1/2-13X2.5-IN) | 8 | |
| 8M8162 | 34 BOLT-12 POINT HEAD (5/16-18X1.5-IN) | 4 | |
| 9H5548 | 35 SEAL-O-RING | 1 | |
| 4D1577 | 36 SEAL-O-RING | 1 |
