System And Components
487-2018 PUMP GP-HYDRAULICS/N GCS1-UP
Group No: 487-2018
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1124627 | 1 SCREW-LOCK | 2 | |
| 1124628 | 2 SCREW (7/16-20X0.5-IN) | 3 | |
| 2064881 | 3 PLUG-ORIFICE | 2 | |
| 1258601 | 4 PIN-SPRING | 2 | |
| 4228800 | 5 COIL-SOLENOID | 2 | |
| 3694719 | 6 ROTATING GP-MOTOR | 1 | |
| 3232282 | 7 SEAL-O-RING | 1 | |
| 2026535 | 8 PIN | 1 | |
| 3694725 | 9 HEAD GP-PUMP | 1 | |
| 1124629 | 10 SCREW (3/4-16X0.6-IN) | 2 | |
| 1177322 | 11 SEAL-RING | 1 | |
| 6V3865 | 12 SEAL-O-RING | 1 | |
| 4640557 | 13 SEAL-O-RING | 1 | |
| 5494318 | 14 SEAL-O-RING | 1 | |
| 1017401 | 15 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 4 | |
| 1124686 | 16 PIN | 1 | |
| 4230871 | 17 PLATE-WEAR | 1 | |
| 1124630 | 18 SCREW (1-5/16-THD) | 1 | |
| 9S8004 | 19 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 20 SEAL-O-RING | 1 | |
| 3132635 | 21 ACTUATOR GP-PUMP (VIBRATORY) | 1 | |
| 4510464 | 22 PLUG | 1 | |
| 1878001 | 23 SEAL | 1 | |
| 1124626 | 24 PIN | 1 | |
| 4230870 | 25 PLUG-LOCKING | 2 |
