System And Components
8W-0345 WIRING GP-SECONDARY STEERINGS/N 6AB1428-99999
Group No: 8W-0345
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8W3628 | 1 HARNESS AS-STEERING (SECONDARY) | 1 | |
| 9G9150 | 2 CLIP (TAB) | 2 | |
| 4D7794 | 3 CLIP | 1 | |
| 8W3635 | 4 PLATE AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 1 | |
| 1346547 | 5 SWITCH AS-FLOW (OIL) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 3K0360 | 6 SEAL-O-RING | 1 | |
| 8T4896 | 7 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5M3062 | 8 BOLT (3/8-16X0.75-IN) | 1 | |
| 8T4896 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5P8244 | 10 WASHER-HARD (12X22.5X2.5-MM THK) | 1 | |
| 5S7379 | 11 BOLT (3/8-16X0.875-IN) | 1 | |
| 7N3718 | 12 CLIP | 1 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T2437 | 14 FILM-FACE | 1 |
