System And Components
2T-3410 WIRING GP-SCRAPERS/N 2XG898-2598
Group No: 2T-3410 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9B7237 | 1 BOLT (3/8-16X1.25-IN) | 2 | |
| 4D7794 | 2 CLIP | 9 | |
| 1578830 | 3 SENDER AS-FUEL LEVEL | 1 | |
| 1693506 | KIT-DIAL SENSOR | 1 | |
| 4F8824 | 4 SEAL-O-RING | 1 | |
| 7G7053 | 5 GROMMET | 1 | |
| 9G9150 | 7 CLIP | 1 | |
| 7K1181 | 8 STRAP-CABLE | 24 | |
| 5M3062 | 9 BOLT (3/8-16X0.75-IN) | 22 | |
| 8M2770 | 10 CLIP (LOOP) | 11 | |
| 2736359 | 11 GUARD-HOSE | 1 | |
| 7S0530 | 12 CLIP | 4 | |
| 2T0369 | 13 BRACKET AS | 1 | |
| 2T3312 | 14 HARNESS AS-CHASSIS | 1 | |
| 2259165 | 15 HARNESS AS-REAR LIGHTING | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 3T0050 | 16 CLIP | 2 | |
| 2139100 | 17 ALARM AS (BACKUP) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 5P5623 | WIRE-ELECTRICAL (16-GA, BLACK)(0.8-M) | ||
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 9X1813 | SLEEVE (31-CM) | ||
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 25 | |
| 1305300 | 19 CLIP | 1 | |
| 2V8260 | 20 GROMMET | 1 | |
| 6V8801 | 21 NUT (3/8-16-THD) | 1 | |
| 8Y4215 | 22 GASKET | 1 | |
| 0338248 | 23 CLIP (LOOP) | 1 | |
| 5M6755 | 24 SCREW-MACHINE (10-24X0.562-IN) | 6 | |
| 7X0620 | 25 WASHER-HARD (5.5X13X1.6-MM THK) | 6 |
