System And Components
2T-0045 DRIVE GP-ELEVATORS/N 2XG2430-UP
Group No: 2T-0045 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2T0241 | 1 TUBE AS | 1 | |
| 2605877 | 2 SPROCKET (14-TEETH) | 2 | |
| 2T2520 | 3 CLAMP | 1 | |
| 2T3874 | 4 PLATE | 1 | |
| 2T3889 | 5 SHAFT AS | 1 | |
| 8J7893 | SLEEVE-WEAR | 1 | |
| 2T3891 | 6 COVER | 1 | |
| 2T3892 | 7 GASKET | 1 | |
| 6J3120 | 8 MOTOR GP-VANE (ELEVATOR) | 1 | |
| 8I1775 | 9 SHIM (4.76-MM THK) | 2 | |
| 8I2368 | 10 REDUCER GP-ELEVATOR SPEED | 1 | |
| 8I2383 | 11 WASHER-SPECIAL | 2 | |
| 1036168 | 12 BEARING AS-ROLLER | 1 | |
| 0S1589 | 13 BOLT (5/8-11X1.75-IN) | 2 | |
| 1A5576 | 14 BOLT (7/8-9X4.5-IN) | 8 | |
| 1F7958 | 15 NUT-FULL (1/2-13-THD) | 2 | |
| 2B0947 | 16 BOLT (1/2-13X2.25-IN) | 2 | |
| 2J3505 | 17 NUT-FULL (7/8-9-THD) | 16 | |
| 2T3885 | 18 HOUSING | 1 | |
| 5F3999 | 19 SEAL-O-RING | 1 | |
| 5P8245 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P8247 | 21 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 4M6953 | 22 WASHER-HARD (24X38X3.5-MM THK) | 32 | |
| 7X0346 | 23 BOLT (5/8-11X2-IN) | 1 | |
| 7X1560 | 24 SEAL-LIP TYPE | 1 | |
| 7X3326 | 25 BOLT-LOCKING (1/2-13X1.125-IN) | 2 | |
| 8I1411 | 26 PIN | 1 | |
| 8T4122 | 27 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4205 | 28 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T9364 | 29 BOLT (1/4-20X0.625-IN) | 6 | |
| 9X8894 | 30 BOLT (7/8-9X3.75-IN) | 8 |
