8I-2368 REDUCER GP-ELEVATOR SPEEDS/N 2XG1903-UP

Group No: 8I-2368 · Commonality

Part Number	Part Name	Qty
1P3934	1 CUP-BEARING	2
1P3935	2 CONE-BEARING	2
2P8386	3 SPACER-BEARING (90X98X5.5MM THK)	1
2T1287	4 BRACKET	1
2T1289	5 BRACKET	1
2T2740	6 CONTAINER-BEARING	1
2T3248	7 PLATE-RETAINER	1
2T3249	8 SHIM PACK (INCLUDES 22-SHIMS)	1
2995512	9 SHAFT-OUTPUT	1
2T3251	10 GEAR-SUN (12-TEETH)	1
3G6234	11 COVER-FLYWHEEL	1
3G6235	12 CARRIER-PLANETARY	1
3G6237	13 GEAR-INPUT PLANETARY (29-TEETH)	3
3G6238	14 GEAR-PLANETARY (24-TEETH)	3
3G6239	15 GEAR-INPUT SUN (14 TEETH)	1
3G6241	16 GEAR-RING (72, 60-TEETH)	1
3G6242	17 FLYWHEEL	1
4B4550	18 FITTING-PRESSURE RELIEF (1/8-27 PTF)	1
5J3946	19 PLUG-VENT (OIL DRAIN)	1
5K5288	20 SEAL GP-DUO-CONE	1
5K5129	RING-SEALING	1
8I1556	21 CARRIER-OUTPUT	1
8I2163	22 PLUG	1
8I2164	23 BREATHER (ELEVATOR SPEED REDUCER)	1
8I2359	24 HOUSING	1
8J7199	25 RING-RETAINING	1
8J7634	26 SLEEVE-WEAR	2
8J7638	27 SPACER-BEARING	1
8J7641	28 SPACER-BEARING (1.8X2.1X.20 IN THK)	3
8J7650	29 BEARING-ROLLER	6
8J7651	30 BEARING-ROLLER	6
0455106	31 PIN-SPRING	3
2F3628	32 PLUG-PIPE	2
2B0858	33 PLUG-PIPE	2
2J7550	34 RING-RETAINING	2
3D2824	35 SEAL-O-RING	1
3G6244	36 SHAFT-PLANETARY	3
3G6245	37 SHAFT-PLANETARY	3
3G6246	38 WASHER-THRUST (46X70X1.85MM THK)	6
3G6247	39 WASHER-THRUST (62X89X2.31MM THK)	6
4B3665	40 BALL BEARING	2
5B7017	41 SEAL-LIP TYPE	2
5H3182	42 PIN-SPRING	6
5P8245	43 WASHER-HARD (13.5X25.5X3-MM THK)	16
6L8535	44 BOLT (1/2-13X1.5-IN)	3
8F9960	45 SEAL-O-RING	1
8J7636	46 RING-RETAINING	1
9F2247	47 PLUG-PIPE (1/8-27-THD)	1
9S1366	48 BOLT (1/2-13X2.5-IN)	16
9S4368	49 RING-RETAINING	2
