System And Components
2T-3212 CONDENSER & MTG GP-REFRIGERANTS/N 9XG1-UP
Group No: 2T-3212 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2T0663 | 1 CONDENSER | 1 | |
| 2T3493 | 2 HOSE AS | 1 | |
| 5P7488 | COUPLING | 1 | |
| 5P7760 | HOSE (320 CM) | ||
| 7X1459 | COUPLING (90 DEG) | 1 | |
| 8T9364 | 3 BOLT (1/4-20X0.625-IN) | 4 | |
| 5M3062 | 4 BOLT (3/8-16X0.75-IN) | 1 | |
| 8T4896 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 2T3485 | 6 HOSE AS | 1 | |
| 5P5664 | HOSE (18.27 M) | ||
| 5P2493 | COUPLING | 1 | |
| 6V2446 | COUPLING-AIR CONDITIONER | 1 | |
| 9W0616 | 7 COUPLER-QUICK | 2 | |
| 0617208 | 8 CLAMP-TUBE | 1 | |
| 6V8801 | 9 NUT (3/8-16-THD) | 4 | |
| 2T3736 | 10 PLATE | 1 | |
| 3E3535 | 11 DRYER AS-REFRIGERANT (IN-LINE) | 1 | |
| 2T3904 | 12 HOSE AS | 1 | |
| 2T3917 | 13 HOSE AS | 1 | |
| 1P6356 | 14 PLATE | 1 | |
| 2T3732 | 15 HOSE AS | 1 | |
| 5P6935 | COUPLING (90 DEG) | 1 | |
| 5P7760 | HOSE (93 CM) | ||
| 7X1459 | COUPLING | 1 | |
| 5P7854 | 16 CLIP (LOOP) | 1 | |
| 0617211 | 17 CLAMP AS | 1 | |
| 3E7320 | 18 ACCUMULATOR-REFRIGERANT | 1 | |
| 5P4115 | 19 WASHER-HARD (7.2X19X2-MM THK) | 12 | |
| 8T8639 | 20 SWITCH AS-PRESSURE (REFRIGERANT) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7X1462 | 21 FITTING AS | 1 | |
| 2L1224 | CAP-SEAL (HIGH SIDE)(7/16 X 20 THD) | 2 | |
| 8C5248 | CAP | 2 | |
| 6V0880 | 22 FITTING AS | 1 | |
| 2L1224 | CAP-SEAL (HIGH SIDE) | 1 | |
| 6M5062 | 23 SEAL-O-RING | 3 | |
| 5L4758 | 24 SEAL-O-RING | 4 | |
| 0L0639 | 25 BOLT (3/8-24X2.25-IN) | 1 | |
| 2T3678 | 26 PLATE | 1 | |
| 5F9144 | 27 SEAL-O-RING | 2 | |
| 1S8947 | 28 SEAL-O-RING | 3 | |
| 6D4636 | 29 CLIP (LOOP) | 2 | |
| 2T1039 | 30 PLATE | 4 | |
| 6V8189 | 31 NUT (5/16-18-THD) | 4 |
