System And Components
451-5456 SUSPENSION GP-SEATS/N 9XG1-UP
Group No: 451-5456 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T9380 | 1 BOLT (7/16-14X1-IN) | 4 | |
| 1138665 | 3 BUMPER-RUBBER | 3 | |
| 1641234 | 4 PLATE | 1 | |
| 1755052 | 5 SPRING AS-AIR | 1 | |
| 1755054 | 6 CAP | 1 | |
| 1755059 | 7 KIT-ROLLER | 1 | |
| 1862092 | 8 BOOT | 1 | |
| 1862093 | 9 BLOCK | 2 | |
| 1862094 | 10 RETAINER | 1 | |
| 1862098 | 11 KIT-FASTENER | 1 | |
| 1862099 | 12 KIT-TETHER | 1 | |
| 2464311 | 13 GUARD (SWITCH) | 1 | |
| 2746719 | 14 SENSOR GP-PRESSURE (AIR SUSPENSION SEAT) | 1 | |
| 3848595 | 16 KIT-VALVE | 1 | |
| 4258951 | 17 SWITCH AS-ROCKER (DAMPENING) | 1 | |
| 3883554 | 18 CONTROL GP-ELECTRONIC (RIDE CONTROL) | 1 | |
| 3893198 | 19 KIT-SEAT SUSPENSION | 1 | |
| 3893200 | 20 KIT-RECEPTACLE CONNECTOR | 1 | |
| 3893201 | 21 KIT-SEAT AIR COMPRESSOR | 1 | |
| 3910258 | 22 FILM-INSTRUCTION (SEAT ADJUSTMENT) | 1 | |
| 3926383 | 23 KIT-SHOCK ABSORBER | 1 | |
| 4196114 | 24 BRACKET-MOUNTING | 1 | |
| 4759153 | 25 WIRING GP-SEAT | 1 | |
| 0314155 | 26 LOCKNUT (5/16-18-THD) | 3 | |
| 0338755 | 27 SCREW (1/4-20X1-IN) | 3 | |
| 0S0509 | 28 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1617 | 29 BOLT (5/16-18X0.75-IN) | 2 | |
| 0S1620 | 30 BOLT (1/2-13X0.75-IN) | 1 | |
| 1D4669 | 31 BOLT-CARRIAGE (1/4-20X1-IN) | 2 | |
| 2D6235 | 32 LOCKNUT (1/4-20-THD) | 4 | |
| 4K9429 | 34 RIVET-POP | 4 | |
| 5P0537 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5P8245 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 7X2501 | 38 BOLT (1/4-20X1.25-IN) | 2 | |
| 8T4205 | 39 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 4404581 | SOFTWARE GP-MACHINE | 1 |
