System And Components
8I-2388 REDUCER GP-ELEVATOR SPEEDPART OF 251-1865 DRIVE GP-ELEVATOR
Group No: 8I-2388
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8I2197 | 1 HOUSING | 1 | |
| 2T2743 | 2 CONTAINER-BEARING | 1 | |
| 2T0192 | 3 COVER-FLYWHEEL | 1 | |
| 2T0193 | 4 CARRIER-PLANETARY | 1 | |
| 2T0194 | 5 CARRIER-PLANETARY | 1 | |
| 2T0195 | 6 FLYWHEEL | 1 | |
| 2T0196 | 7 GEAR-OUTPUT RING (76-TEETH) | 1 | |
| 2T0197 | 8 GEAR-INPUT RING (72-TEETH) | 1 | |
| 2T0198 | 9 GEAR-PLANETARY (28-TEETH) | 3 | |
| 6V5117 | 10 BALL BEARING | 2 | |
| 2T0199 | 11 GEAR-PLANETARY (29-TEETH) | 3 | |
| 2T0200 | 12 GEAR-INPUT SUN (12-TEETH) | 1 | |
| 2T0201 | 13 GEAR-SUN (17-TEETH) | 1 | |
| 2T0202 | 14 SHAFT-INPUT | 1 | |
| 2T2759 | 15 SHAFT-OUTPUT | 1 | |
| 6V5115 | 16 BEARING AS-ROLLER (CAGED) | 6 | |
| 6V5116 | 17 BEARING AS-ROLLER (CAGED) | 3 | |
| 0300060 | 18 CUP-BEARING | 2 | |
| 0300061 | 19 CONE-BEARING | 2 | |
| 2P7555 | 20 SPACER-BEARING | 1 | |
| 3S0303 | 21 SEAL GP-DUO-CONE | 1 | |
| 7F2122 | 22 SEAL-O-RING | 1 | |
| 2H3919 | 23 SEAL-LIP TYPE | 2 | |
| 6V5862 | 24 SEAL-O-RING | 1 | |
| 2T0207 | 25 WASHER-THRUST | 1 | |
| 2T0212 | 26 WASHER-THRUST | 6 | |
| 2T0213 | 27 WASHER-THRUST | 6 | |
| 0616712 | 28 RING-RETAINING | 1 | |
| 2T0208 | 29 SPACER | 1 | |
| 5K9065 | 30 RING-RETAINING | 1 | |
| 2R1236 | 31 RING-RETAINING (LOCK, INTERNAL) | 1 | |
| 7J5826 | 32 SLEEVE-WEAR | 2 | |
| 5J3946 | 33 PLUG-VENT | 1 | |
| 2F3628 | 34 PLUG-PIPE | 1 | |
| 8I2163 | 35 PLUG | 1 | |
| 2T0204 | 36 SHAFT-INPUT GEAR (PLANET) | 3 | |
| 2T0205 | 37 SHAFT-OUTPUT GEAR (PLANET) | 3 | |
| 5H3182 | 38 PIN-SPRING | 6 | |
| 2T2626 | 39 PLATE-DRIVE (OUTPUT) | 1 | |
| 2T2760 | 40 WASHER | 1 | |
| 9F2247 | 41 PLUG-PIPE | 2 | |
| 0L2090 | 42 BOLT (7/8-14X3.75-IN) | 1 | |
| 4B4550 | 43 FITTING-PRESSURE RELIEF (1/8-27 PTF) | 1 | |
| 1A1460 | 44 BOLT (1/2-13X2-IN) | 16 | |
| 5P8245 | 45 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 2T2814 | 46 SPACER-BEARING | 1 | |
| 8I2164 | 49 BREATHER (ELEVATOR SPEED REDUCER) | 1 | |
| 3D2824 | 50 SEAL-O-RING | 1 | |
| 2B0858 | 51 PLUG-PIPE | 1 |
