System And Components
329-8940 AIR CONDITIONER GPS/N TFJ1-UP
Group No: 329-8940 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5464 | 1 SWITCH AS-THERMOSTAT (HVAC) | 1 | |
| 8C3756 | 2 FILM-IDENTIFICATION (AIR CONDITIONER) | 1 | |
| 1343518 | 3 TIE-PUSH MOUNT | 2 | |
| 2478302 | 5 RIVET | 8 | |
| 2575029 | 6 RESISTOR AS | 1 | |
| 2593222 | 7 FILTER ELEMENT-AIR (STANDARD EFFICIENCY)(CAB HEATER, AIR CONDITIONER) | 1 | |
| 2756658 | 8 PAN GP-DRAIN (AIR CONDITIONER) | 1 | |
| 3428127 | 9 COIL AS-EVAPORATOR | 1 | |
| 3254416 | STUD (M8X1.25X52-MM) | 2 | |
| 3270282 | SEAL-INTEGRAL (1/2-IN) | 1 | |
| 3270283 | SEAL-INTEGRAL (3/4-IN) | 1 | |
| 2756702 | 15 PLATE AS | 1 | |
| 2756706 | 17 MOTOR AS-BLOWER (24-VOLT)(HEATER, A/C) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 2756708 | 18 PLATE | 1 | |
| 2756709 | 19 PLATE | 1 | |
| 2756710 | 20 RETAINER (PUSH ON) | 1 | |
| 2922905 | 21 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 8 | |
| 3428130 | 23 CASE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 17 | |
| 7T1099 | LINK | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 1658718 | NUT-WELD (M4X0.7-THD) | 4 | |
| 3522194 | 24 HARNESS AS-MOTOR (AIR CONDITIONER) | 1 | |
| 0964034 | 25 BOLT-WING (M6X1X15-MM) | 1 | |
| 0966166 | 26 WASHER-HARD (4.5X9X1-MM THK) | 12 | |
| 3511770 | 27 COIL GP-HEATER | 1 | |
| 3B4501 | 28 LOCKWASHER | 2 | |
| 5C9553 | 29 BOLT (M6X1X16-MM) | 21 | |
| 8C8514 | 30 SCREW-MACHINE (8-32X0.375-IN) | 2 | |
| 8T0337 | 31 SCREW-MACHINE (M4X0.7X12-MM) | 12 | |
| 8T4205 | 32 WASHER-HARD (7.2X14.5X2-MM THK) | 22 | |
| 3620658 | 33 GASKET | 1 | |
| 2948679 | KIT-GASKET (AIR CONDITIONER) | 1 |
