System And Components
428-9139 LINES GP-POWER TRAIN OILS/N WSJ1-UP
Group No: 428-9139
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1089422 | 1 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1488333 | 2 CONNECTOR AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T7927 | CONNECTOR | 1 | |
| 1488347 | 3 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488364 | 4 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488381 | 5 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T5429 | ELBOW | 1 | |
| 1488406 | 6 PLUG AS | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 1488407 | 7 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488411 | 8 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1645544 | 9 ELBOW AS | 1 | |
| 3E2333 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1645567 | 10 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1646872 | 11 TEE AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 1158634 | TEE-O-RING | 1 | |
| 1705715 | 12 SEAL-O-RING | 1 | |
| 1731437 | 13 FLANGE-HALF | 4 | |
| 1984777 | 14 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 1984778 | 15 WASHER-HARD (13.5X30X12-MM THK) | 5 | |
| 1P3704 | 16 SEAL-RECTANGULAR | 3 | |
| 1P4576 | 17 FLANGE-HALF | 2 | |
| 1P4577 | 18 FLANGE-HALF | 2 | |
| 1P4579 | 19 FLANGE-HALF | 4 | |
| 1P4582 | 20 FLANGE-HALF | 4 | |
| 1S0994 | 21 CLIP (LOOP) | 2 | |
| 2006345 | 22 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2465451 | 23 STUD-TAPERLOCK (M12X1.75X65-MM) | 1 | |
| 2622603 | 24 SPACER (13.5X30X16-MM THK) | 1 | |
| 2681516 | 25 TEE AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 2681515 | TEE | 1 | |
| 2812592 | 26 PIN-TAPERLOCK | 1 | |
| 2815934 | 27 ELBOW AS | 1 | |
| 6V9877 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2S7850 | 28 PUMP GP-GEAR | 1 | |
| 3196213 | 29 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196222 | 30 ELBOW AS | 1 | |
| 6V9200 | ELBOW | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3293356 | 31 NUT (M12X1.75-THD) | 2 | |
| 3445675 | 32 NUT (M10X1.5-THD) | 2 | |
| 4992665 | 33 HOSE AS | 1 | |
| 4992666 | 34 HOSE AS | 1 | |
| 4992668 | 35 HOSE AS | 1 | |
| 4992672 | 36 HOSE AS | 1 | |
| 4992677 | 37 HOSE AS | 1 | |
| 4999212 | 38 HOSE AS | 1 | |
| 4J0520 | 39 SEAL-O-RING | 3 | |
| 4J0522 | 40 SEAL-O-RING | 2 | |
| 4J0524 | 41 SEAL-O-RING | 2 | |
| 4J0527 | 42 SEAL-O-RING | 2 | |
| 4J5267 | 43 SEAL-O-RING | 1 | |
| 4L9337 | 44 BOLT (3/8-16X1.5-IN) | 8 | |
| 5017926 | 45 PLATE AS | 1 | |
| 8Y3795 | BOSS (M10X1.5X40-MM) | 1 | |
| 5458602 | 46 HOSE AS | 1 | |
| 5460177 | 47 HOSE AS | 1 | |
| 5502394 | 48 FILTER GP-OIL | 1 | |
| 5690655 | 49 HOSE AS | 1 | |
| 5690656 | 50 TUBE AS | 1 | |
| 5713959 | 51 HOSE AS | 1 | |
| 5713960 | 52 HOSE AS | 1 | |
| 5713962 | 53 TUBE AS | 1 | |
| 5866780 | 54 TUBE AS | 1 | |
| 5866781 | 55 TUBE AS | 1 | |
| 5D6149 | 56 SCREEN AS (POWER TRAIN OIL) | 1 | |
| 5K5338 | 57 CLIP (LOOP) | 1 | |
| 5K9090 | 58 SEAL-O-RING | 2 | |
| 6C3241 | 59 BOLT (1/2-13X1.5-IN) | 8 | |
| 5P7466 | 60 CLIP (SLOT) | 2 | |
| 5P7467 | 61 CLIP (TAB) | 2 | |
| 5P7468 | 62 CLIP (SLOT) | 2 | |
| 5P7469 | 63 CLIP (TAB) | 2 | |
| 5P8112 | 64 GROMMET | 2 | |
| 6V0545 | 65 GROMMET | 2 | |
| 6V0852 | 66 CAP-DUST | 3 | |
| 6V1876 | 67 GROMMET | 1 | |
| 6V1889 | 68 CLIP (LOOP) | 2 | |
| 7G5984 | 69 CLIP (TAB) | 1 | |
| 7G5985 | 70 CLIP (SLOT) | 1 | |
| 7K1181 | 71 STRAP-CABLE | 2 | |
| 7X0292 | 72 BOLT (3/8-16X4.5-IN) | 2 | |
| 7X7729 | 73 WASHER (11X25X3-MM THK) | 3 | |
| 8M5661 | 74 SEAL-O-RING | 1 | |
| 8S0023 | 75 CLIP (SLOT) | 3 | |
| 8S0024 | 76 CLIP (TAB) | 3 | |
| 8T4121 | 77 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | 78 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4137 | 79 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4139 | 80 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4172 | 81 BOLT (M10X1.5X80-MM) | 4 | |
| 8T4183 | 82 BOLT (M12X1.75X40-MM) | 12 | |
| 8T4184 | 83 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4192 | 84 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4194 | 85 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4195 | 86 BOLT (M10X1.5X30-MM) | 2 | |
| 1837121 | 87 BOLT (M10X1.5X35-MM) | 5 | |
| 8T4223 | 88 WASHER-HARD (13.5X25.5X3-MM THK) | 38 | |
| 8T4896 | 89 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8T4910 | 90 BOLT (M12X1.75X60-MM) | 9 | |
| 8T6466 | 91 BOLT (M10X1.5X60-MM) | 4 | |
| 8W3645 | 92 SCREEN AS (TRANSFER CASE) | 1 | |
| 8X7517 | 93 BRACKET AS | 1 | |
| 2W7940 | BRACKET | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 9M8406 | 94 CLIP (LOOP) | 1 |
