System And Components
5T-1250 DIFFERENTIAL & BEVEL GEAR GPS/N 3WJ1-99999
Group No: 5T-1250
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D0307 | 1 CAP-FILLER (DIFFERENTIAL) | 1 | |
| 4D0306 | 2 GASKET-CAP | 1 | |
| 5T9093 | 3 GAUGE-OIL LEVEL (DIPSTICK) | 1 | |
| 1505411 | 4 TUBE AS | 1 | |
| 5H7844 | 5 GASKET | 1 | |
| 6V4463 | 6 BOLT-LOCKING (1/2-13X1.375-IN) | 2 | |
| 5P8245 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6K7917 | 8 BOLT-LOCKING (1/2-13X1-IN) | 1 | |
| 6D4164 | 9 LOCK | 1 | |
| 5F0304 | 10 PLUG-DRAIN (5/8-18-THD) | 1 | |
| 4B8407 | 11 GASKET-COPPER | 1 | |
| 6D9877 | 12 YOKE AS | 1 | |
| 5P1086 | 13 SEAL-LIP TYPE | 1 | |
| 6V4463 | 14 BOLT-LOCKING (1/2-13X1.375-IN) | 14 | |
| 5P7213 | 15 WASHER-HARD (13.5X20.5X2-MM THK) | 6 | |
| 6D4167 | 16 SHIM (0.005-IN THK) | 6 | |
| 6D4168 | 17 SHIM (0.007-IN THK) | 8 | |
| 5T1150 | 18 CARRIER-DIFFERENTIAL | 1 | |
| 9F1399 | 19 SEAL-O-RING | 1 | |
| 3F3049 | 20 CONE-BEARING | 1 | |
| 4J1253 | 21 SEAL-O-RING | 1 | |
| 2D9190 | 22 CUP-BEARING | 1 | |
| 2D9191 | 23 CONE-BEARING | 1 | |
| 6V0347 | 24 CONE-BEARING | 1 | |
| 8W6757 | 25 DIFFERENTIAL GP | 1 | |
| 6D4169 | 26 RING-ADJUSTMENT | 1 | |
| 6F2956 | 27 CUP-BEARING | 1 | |
| 6D4191 | 28 CAGE | 1 | |
| 6D4188 | 29 COVER | 1 | |
| 4K0367 | 30 NUT-FULL (5/8-11-THD) | 15 | |
| 2S5658 | 31 WASHER-HARD (17X29X3-MM THK) | 35 | |
| 6D9467 | 32 GEAR-DIFFERENTIAL RING | 1 | |
| 6V8188 | 33 NUT (1/2-13-THD) | 12 | |
| 5P8245 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 6B3223 | 35 CUP-BEARING | 1 | |
| 3E4307 | 36 BOLT-LOCKING (5/8-11X1.75-IN) | 20 | |
| 6D7615 | 37 SHIM (0.005-IN THK) | 7 | |
| 6D7616 | 38 SHIM (0.007-IN THK) | 8 | |
| 2K2939 | 39 SEAL-O-RING | 1 | |
| 3F1396 | 40 CONE-BEARING | 1 | |
| 8B6343 | 41 CUP-BEARING | 1 | |
| 6D4189 | 42 RETAINER-BEARING | 1 | |
| 6D9398 | 43 PINION-DIFFERENTIAL | 1 | |
| 7D7206 | 44 RETAINER | 1 | |
| 1S9292 | 45 DOWEL | 4 | |
| 5M1932 | 46 STUD-TAPERLOCK (1/2-13X2.17-IN) | 12 | |
| 5M7329 | 47 SEAL-O-RING | 1 |
