System And Components
8W-7601 CASE & FRAME GPS/N 7CG1-99999
Group No: 8W-7601
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8W6890 | 1 CASE & FRAME AS | 1 | |
| 9D1205 | 2 BLOCK | 1 | |
| 8D8882 | 3 PLATE | 1 | |
| 5H9394 | 4 BOSS (1/2-13X1-IN) | 3 | |
| 8W3980 | 5 BLOCK | 1 | |
| 8D3508 | 6 BOSS (3/8-16X1-IN) | 1 | |
| 8W7100 | 7 FRAME AS | 1 | |
| 8J1196 | 8 LUG (3/8-16-THD) | 1 | |
| 8K0273 | 9 BOSS (1/2-13-THD) | 6 | |
| 9D6164 | 10 BOSS (3/8-16X1.44-IN) | 2 | |
| 4D9376 | 11 BOSS (3/8-16-THD) | 4 | |
| 5T0492 | 12 SUPPORT AS | 1 | |
| 5T0844 | 13 SUPPORT AS | 1 | |
| 8W7468 | 14 BUMPER AS | 1 | |
| 8W7029 | 15 BUMPER AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 6 | |
| 4D8128 | 16 COUPLING | 1 | |
| 7P3248 | 17 HINGE | 2 | |
| 5T0261 | 18 BUMPER AS | 1 | |
| 9F2978 | 19 NUT-WELD (3/8-16-THD) | 4 | |
| 5T0037 | 20 SUPPORT AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 5 | |
| 5T0136 | 21 SUPPORT AS | 1 | |
| 4D6293 | 22 BOSS (3/8-16X1.31-IN) | 3 | |
| 9G0028 | 23 BOSS AS (3/8-16X0.62-IN) | 2 | |
| 4K2543 | BOSS (3/8-16-THD) | 1 | |
| 8S1783 | PLATE-GROUNDING | 1 | |
| 2G2081 | 24 BOSS (1/2-13-THD) | 2 | |
| 8D7188 | 25 HANGER | 2 | |
| 8F9836 | 26 BOSS (3/8-16-THD) | 3 | |
| 8W9664 | 27 PLATE | 1 | |
| 8W6828 | 28 CASE AS-DIFFERENTIAL | 1 | |
| 3V2793 | 29 EYE | 2 | |
| 8D3483 | 30 BRACKET-HITCH | 1 | |
| 4M4649 | 31 PLATE-LOCK | 1 | |
| 3S8596 | 32 LUG | 10 | |
| 8W7105 | 33 FRAME AS | 1 | |
| 8D8831 | 34 PLATE | 1 | |
| 8X0547 | 35 BUMPER AS | 1 | |
| 5P9743 | 36 BOSS-WELD | 1 | |
| 7B0863 | 37 LATCH-PIN | 1 | |
| 9S8184 | 38 PIN AS-DRAWBAR | 1 | |
| 7X0365 | 39 BOLT (3/4-10X1.5-IN) | 4 | |
| 0S1577 | 40 BOLT (5/8-18X2.25-IN) | 1 | |
| 2K4821 | LOCKNUT (5/8-18-THD) | 1 | |
| 8W3430 | 41 STEP AS | 2 | |
| 8W7466 | 42 PLATE | 1 | |
| 4L6454 | 43 BOLT (3/8-16X1-IN) | 30 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 30 | |
| 8W4834 | 44 PLATE AS | 1 | |
| 5T1815 | 45 ROD AS | 6 | |
| 1A6240 | WASHER (0.328X0.75X0.065-IN THK) | 2 | |
| 3B4615 | PIN-COTTER | 2 | |
| 5P8502 | 46 PADLOCK GP | 1 | |
| 5P8500 | KEY | 2 | |
| 6V5874 | COVER | 1 | |
| 2Y4071 | PADLOCK (BRAZIL USAGE) | 1 | |
| 5T7441 | 47 COVER AS | 1 | |
| 4D6082 | 48 BOLT (1/2-13X1.5-IN) | 1 | |
| 3B4610 | PIN-COTTER | 1 | |
| 0T0883 | WASHER (0.531X1X0.065-IN THK) | 1 | |
| 8T4223 | 49 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 4D0309 | 50 CAP-FILLER (TRANSMISSION) | 1 | |
| 6F5188 | SEAL-RING | 1 | |
| 8W0284 | 51 TUBE AS | 1 | |
| 8D4926 | 52 COVER | 1 | |
| 5S3676 | SEAL-O-RING | 1 | |
| 3D8439 | 53 STUD (5/8-11X3.4-IN)(86MM) | 18 | |
| 4K7463 | 54 SEAL-LIP TYPE | 2 | |
| 8D8829 | 55 BUSHING | 2 | |
| 6G0078 | 56 BREATHER | 2 | |
| 1N8559 | 57 TEE-SERVICE | 1 | |
| 3D0490 | 58 STUD-TAPERLOCK (1/2-13X1.97-IN) | 6 | |
| 8B6599 | 59 PLUG-DRAIN (MAGNETIC) | 2 | |
| 0L1124 | GASKET-PLUG | 2 | |
| 8J7596 | 60 BUSHING | 2 | |
| 5P1291 | 61 HOSE (22CM) | ||
| 5P0597 | CLAMP-HOSE | 4 | |
| 7D2838 | 62 STUD (7/8-9X3.15-IN) | 6 | |
| 2D9345 | 63 STUD (5/8-11-THD)(65MM) | 2 | |
| 5M1932 | 64 STUD-TAPERLOCK (1/2-13X2.17-IN) | 4 | |
| 6V8188 | NUT (1/2-13-THD) | 4 | |
| 8W6112 | 65 ELBOW AS | 1 | |
| 5T5211 | GAUGE-SIGHT | 1 | |
| 5T7100 | 66 GASKET | 2 | |
| 4D0307 | 67 CAP-FILLER (DIFFERENTIAL) | 1 | |
| 4D0306 | GASKET-CAP | 1 | |
| 8W6111 | 68 ELBOW AS | 1 | |
| 5T5211 | GAUGE-SIGHT | 1 |
