System And Components
3T2649 ELECTRIC STARTING MOTOR GROUP--24 Volt--Delco-Remy--Part 1 of 3Part of 6N1889 Electric Starting Motor Group listed on Page 95
Group No: 3T2649
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0369823 | 1 BOLT | 4 | |
| 7L2894 | 2 GASKET | 2 | |
| 3T4701 | 3 FRAME AS-END | 1 | |
| 3T3423 | 4 CUP | 1 | |
| 9G4513 | 5 BUSHING | 1 | |
| 3T3424 | 6 PLUG-FELT | 1 | |
| 3H3680 | 7 NUT-JAM | 2 | |
| 8F5368 | 8 WASHER | 1 | |
| 4M1868 | 9 ARMATURE AS | 1 | |
| 8H1141 | 10 SHOE-POLE | 4 | |
| 5L8963 | 11 COIL AS-FIELD | 1 | |
| 9H3757 | 12 WASHER | 2 | |
| 4B4280 | 13 WASHER | 2 | |
| 4M1841 | 14 CONNECTOR | 1 | |
| 3L3380 | 15 BUSHING | 1 | |
| 3T3421 | 16 SOLENOID AS | 1 | |
| 6H3622 | 17 SCREW-MACHINE | 4 | |
| 4M1831 | 18 PLUG-LEVER HOUSING | 2 | |
| 3F0379 | 19 SCREW-POLE SHOE | 8 | |
| 2N3145 | 20 INSULATOR-COIL | 1 | |
| 3N3763 | KIT-TERMINAL | 1 |
