System And Components
123-5086 CASE & FRAME GPS/N 1NB1390-UP
Group No: 123-5086
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8X0516 | 1 BUMPER AS | 1 | |
| 8X0546 | GUARD-BUMPER | 2 | |
| 9D2078 | PIPE | 2 | |
| 9D6124 | HOOK-LIFT | 2 | |
| 5T4616 | 2 PLATE AS | 1 | |
| 5T9901 | TREAD | 1 | |
| 6C3680 | RIVET-POP | 16 | |
| 8D3508 | BOSS (3/8-16X1-IN) | 1 | |
| 4L6454 | 3 BOLT (3/8-16X1-IN) | 20 | |
| 5H4909 | 4 SEAL-O-RING | 1 | |
| 8T5361 | 5 WASHER-HARD (28X49X5-MM THK) | 8 | |
| 9S1363 | 6 BOLT (1-8X2.75-IN) | 8 | |
| 8W6111 | 7 ELBOW AS | 1 | |
| 5T5211 | GAUGE-SIGHT | 1 | |
| 4D0309 | 8 CAP-FILLER (TRANSMISSION) | 1 | |
| 8T4223 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 6F5188 | 10 SEAL-RING | 1 | |
| 1181222 | 11 TUBE AS | 1 | |
| 5T1815 | 12 ROD AS | 1 | |
| 1A6240 | WASHER (0.328X0.75X0.065-IN THK) | 2 | |
| 3B4610 | 13 PIN-COTTER | 1 | |
| 2K4821 | 14 LOCKNUT (5/8-18-THD) | 1 | |
| 4D6082 | 15 BOLT (1/2-13X1.5-IN)(1/2-13X1.50 IN) | 1 | |
| 5S7379 | 16 BOLT (3/8-16X0.875-IN) | 8 | |
| 8T9393 | 17 BOLT (5/8-11X1.5-IN) | 12 | |
| 2D5238 | 18 STUD-TAPERLOCK (5/8-11X2.5-IN) | 2 | |
| 3D8439 | 19 STUD (5/8-11X3.4-IN) | 17 | |
| 6G9061 | 20 COVER | 1 | |
| 7X0591 | 21 WASHER-HARD (17X29X3-MM THK) | 12 | |
| 6V8188 | 22 NUT (1/2-13-THD) | 4 | |
| 4D0306 | 23 GASKET-CAP | 1 | |
| 4D0307 | 24 CAP-FILLER (DIFFERENTIAL) | 1 | |
| 6V0439 | 25 PLUG-MAGNETIC | 2 | |
| 5P7815 | 26 SEAL-O-RING | 2 | |
| 8W6112 | 27 ELBOW AS | 1 | |
| 5T5211 | GAUGE-SIGHT | 1 | |
| 7X3193 | 28 BOLT (5/8-18X3.25-IN) | 1 | |
| 9D4094 | 29 BEARING | 2 | |
| 8S5767 | 30 SEAL-LIP TYPE | 2 | |
| 9J0945 | 31 BUSHING-TERMINAL | 2 | |
| 5T0320 | 32 PLATE | 1 | |
| 5P8502 | 33 PADLOCK GP | 1 | |
| 5P8500 | KEY | 2 | |
| 6V5874 | COVER | 1 | |
| 2Y4071 | PADLOCK (INCLUDES 2 KEYS) | 1 | |
| 1A6240 | 34 WASHER (0.328X0.75X0.065-IN THK) | 2 | |
| 8X2735 | 35 COVER AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 6C3680 | RIVET-POP | 12 | |
| 7G9787 | LUG | 1 | |
| 5P4868 | 36 CLAMP-HOSE | 4 | |
| 3B4615 | 37 PIN-COTTER | 2 | |
| 6G0078 | 38 BREATHER | 2 | |
| 9S8184 | 39 PIN AS-DRAWBAR | 1 | |
| 7B0863 | 40 LATCH-PIN | 1 | |
| 1273001 | 41 STEP AS | 2 | |
| 9V1899 | COLLAR | 4 | |
| 7X0365 | 42 BOLT (3/4-10X1.5-IN) | 4 | |
| 2G6077 | 43 HOSE | 1 | |
| 5T7100 | 44 GASKET | 2 | |
| 8T4896 | 45 WASHER-HARD (10.2X18.5X2.5-MM THK) | 28 | |
| 5M1932 | 46 STUD-TAPERLOCK (1/2-13X2.17-IN) | 4 | |
| 8W7599 | 47 CASE & FRAME AS | 1 | |
| 3R0451 | 48 BOSS (3/8-16-THD) | 2 | |
| 8W7458 | 49 BOSS (3/4-10-THD) | 4 | |
| 5K8612 | 50 BAR | 2 | |
| 9D5659 | 51 BOSS (3/8-16X1.19-IN) | 8 | |
| 9D6166 | 52 BOSS (3/8-16-THD) | 5 | |
| 8X2769 | 53 BUMPER AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 6 | |
| 9D5567 | 54 BOSS (3/8-16X2.44-IN) | 6 | |
| 8W7939 | 55 FRAME AS | 1 | |
| 6G8892 | 56 BUMPER AS | 1 | |
| 2H8124 | LUG | 5 | |
| 1U4199 | 57 BLOCK | 2 | |
| 5B1983 | 58 BOSS (3/8-16-THD) | 2 | |
| 2G7306 | 59 PLATE | 1 | |
| 2G7598 | 60 BLOCK | 1 | |
| 2G9253 | 61 PLATE | 2 | |
| 3S8596 | 62 LUG | 10 | |
| 2R6816 | 63 BLOCK | 1 | |
| 4D9376 | 64 BOSS (3/8-16-THD) | 4 | |
| 4M4649 | 65 PLATE-LOCK | 1 | |
| 5C3162 | 66 BLOCK | 1 | |
| 5H9394 | 67 BOSS (1/2-13X1-IN) | 2 | |
| 8X8192 | 68 PLATE AS | 1 | |
| 1H7263 | LUG (28MM LG) | 1 | |
| 2H8124 | LUG (30MM LG) | 1 | |
| 6C3680 | RIVET-POP | 8 | |
| 7P3248 | HINGE | 2 | |
| 6G8893 | 69 BUMPER AS | 1 | |
| 2H8124 | LUG | 9 | |
| 8F9836 | 70 BOSS (3/8-16-THD) | 2 | |
| 5T1606 | 71 SUPPORT AS | 1 | |
| 9D1205 | 72 BLOCK | 2 | |
| 9G0028 | 73 BOSS AS (3/8-16X0.62-IN) | 2 | |
| 8S1783 | PLATE-GROUNDING | 1 | |
| 8K0273 | 74 BOSS (1/2-13-THD) | 1 | |
| 9D5571 | 75 BOSS (3/8-16-THD) | 1 | |
| 8G1779 | 76 BOSS | 1 | |
| 8J1196 | 77 LUG (3/8-16-THD) | 1 | |
| 9D2137 | 78 PLATE | 2 | |
| 9D2129 | 79 SUPPORT AS | 1 | |
| 9D2136 | 80 PLATE | 2 | |
| 6H3609 | 81 BOSS | 1 | |
| 8G0863 | 82 BLOCK | 1 | |
| 8X1883 | 83 SUPPORT AS | 1 | |
| 9D2874 | 84 SUPPORT AS | 1 |
