123-5086 CASE & FRAME GPS/N 2PS1-UP

Group No: 123-5086

Part Number	Part Name	Qty
8W7599	1 CASE & FRAME AS	1
5T4616	2 PLATE AS	1
5T9901	TREAD	1
6C3680	RIVET-POP	16
8D3508	BOSS (3/8-16X1-IN)	1
4L6454	3 BOLT (3/8-16X1-IN)	20
5H4909	4 SEAL-O-RING	1
8T5361	5 WASHER-HARD (28X49X5-MM THK)	8
9S1363	6 BOLT (1-8X2.75-IN)	8
8W6111	7 ELBOW AS	1
1445374	GAUGE-SIGHT (TRANSMISSION)	1
4D0309	8 CAP-FILLER (TRANSMISSION)(TRANSMISSION)	1
8T4223	9 WASHER-HARD (13.5X25.5X3-MM THK)	5
6F5188	10 SEAL-RING	1
1181222	11 TUBE AS	1
5T1815	12 ROD AS	1
1A6240	WASHER (0.328X0.75X0.065-IN THK)	2
3B4610	13 PIN-COTTER	1
2K4821	14 LOCKNUT (5/8-18-THD)	1
4D6082	15 BOLT (1/2-13X1.5-IN)	1
5S7379	16 BOLT (3/8-16X0.875-IN)	8
8T9393	17 BOLT (5/8-11X1.5-IN)	12
2D5238	18 STUD-TAPERLOCK (5/8-11X2.5-IN)	2
3D8439	19 STUD (5/8-11X3.4-IN)	17
6G9061	20 COVER	1
7X0591	21 WASHER-HARD (17X29X3-MM THK)	12
6V8188	22 NUT (1/2-13-THD)	4
4D0306	23 GASKET-CAP (DIFFERENTIAL)	1
4D0307	24 CAP-FILLER (DIFFERENTIAL)(DIFFERENTIAL)	1
6V0439	25 PLUG-MAGNETIC (DRAIN)	2
5P7815	26 SEAL-O-RING	2
8W6112	27 ELBOW AS	1
1445374	GAUGE-SIGHT (DIFFERENTIAL)	1
7X3192	28 BOLT (5/8-18X2-IN)	1
9D4094	29 BEARING	2
8S5767	30 SEAL-LIP TYPE	2
9J0945	31 BUSHING-TERMINAL	2
5T0320	32 PLATE	1
2462641	33 PADLOCK GP (BATTERY)	1
5P8500	KEY	2
1A6240	34 WASHER (0.328X0.75X0.065-IN THK)	2
8X2735	35 COVER AS	1
1F0750	NUT-WELD (3/8-16-THD)	4
6C3680	RIVET-POP	12
5T9901	TREAD	1
5P4868	36 CLAMP-HOSE	4
3B4615	37 PIN-COTTER	2
6G0078	38 BREATHER (DIFFERENTIAL)	2
9S8184	39 PIN AS-DRAWBAR	1
7B0863	40 LATCH-PIN	1
1273001	41 STEP AS	2
9V1899	COLLAR	4
7X0365	42 BOLT (3/4-10X1.5-IN)	4
5P1294	43 HOSE (29-CM)
5T7100	44 GASKET	2
8T4896	45 WASHER-HARD (10.2X18.5X2.5-MM THK)	28
5M1932	46 STUD-TAPERLOCK (1/2-13X2.17-IN)	4
2307625	47 BUMPER AS	11
