System And Components
159-0705 CASE & FRAME GPS/N AWK1-UP
Group No: 159-0705
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A6430 | 1 PLATE | 1 | |
| 5P1294 | 2 HOSE (29-CM) | ||
| 4D0306 | 3 GASKET-CAP | 1 | |
| 4D0307 | 4 CAP-FILLER (DIFFERENTIAL)(DIFFERENTIAL) | 1 | |
| 4D0309 | 5 CAP-FILLER (TRANSMISSION)(TRANSMISSION) | 1 | |
| 5T7100 | 6 GASKET | 2 | |
| 6F5188 | 7 SEAL-RING | 1 | |
| 6G0078 | 8 BREATHER (TMSN/DIFF & FINAL DRIVE) | 2 | |
| 6G9061 | 9 COVER | 1 | |
| 7B0863 | 10 LATCH-PIN | 1 | |
| 8T4984 | 11 CLAMP-HOSE | 4 | |
| 8W6111 | 12 ELBOW AS | 1 | |
| 1445374 | GAUGE-SIGHT (TRANSMISSION OIL LEVEL) | 1 | |
| 8W6112 | 13 ELBOW AS | 1 | |
| 1445374 | GAUGE-SIGHT (DIFFERENTIAL OIL LEVEL) | 1 | |
| 9D4094 | 14 BEARING | 2 | |
| 9J0945 | 15 BUSHING-TERMINAL | 2 | |
| 8X7742 | 16 STEP AS | 2 | |
| 1181222 | 17 TUBE AS | 1 | |
| 1590737 | 18 CASE & FRAME AS | 1 | |
| 2307625 | 19 BUMPER AS | 1 | |
| 1844689 | 20 PIN-DRAWBAR | 1 | |
| 2268203 | 21 PLATE-TREAD | 1 | |
| 2D5238 | 22 STUD-TAPERLOCK (5/8-11X2.5-IN) | 2 | |
| 2K4821 | 23 LOCKNUT (5/8-18-THD) | 1 | |
| 3D5963 | 24 STUD-TAPERLOCK (5/8-11X3.5-IN) | 17 | |
| 3K5234 | 25 WASHER-HARD (28X49X6-MM THK) | 8 | |
| 4L6454 | 26 BOLT (3/8-16X1-IN) | 14 | |
| 5H4909 | 27 SEAL-O-RING | 1 | |
| 5M1932 | 28 STUD-TAPERLOCK (1/2-13X2.17-IN) | 4 | |
| 5P1075 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 11 | |
| 5P7815 | 30 SEAL-O-RING | 2 | |
| 6V0439 | 31 PLUG-MAGNETIC (TRANSMISSION DRAIN) | 2 | |
| 6V8188 | 32 NUT (1/2-13-THD) | 4 | |
| 7X0365 | 33 BOLT (3/4-10X1.5-IN) | 4 | |
| 7X0591 | 34 WASHER-HARD (17X29X3-MM THK) | 12 | |
| 7X3192 | 35 BOLT (5/8-18X2-IN) | 1 | |
| 8S5767 | 36 SEAL-LIP TYPE | 2 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4896 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8T9393 | 39 BOLT (5/8-11X1.5-IN) | 12 | |
| 9S1363 | 40 BOLT (1-8X2.75-IN) | 8 |
