System And Components
507-8777 FRAME GP-REARS/N WSJ1-UP
Group No: 507-8777
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1U0138 | 1 PIN AS | 2 | |
| 1U3582 | 2 TRUNNION | 2 | |
| 3G6077 | 3 SHOE-WEAR | 2 | |
| 4J9772 | 4 RETAINER | 2 | |
| 4J9773 | 5 PIN | 1 | |
| 8J4155 | 6 CAP-BEARING | 2 | |
| 8X4913 | 7 ARM AS-DRAFT FRAME | 2 | |
| 3J3532 | 7A LUG | 2 | |
| 4T0538 | 7B BEARING-ARM | 1 | |
| 8X4914 | 7C SPREADER AS | 1 | |
| 8X4916 | 8 PLATE | 2 | |
| 5870974 | 9 BRACKET AS | 1 | |
| 3J2373 | 9A BUSHING | 1 | |
| 3344466 | 10 WASHER (28X49X8-MM THK) | 144 | |
| 3463300 | 11 SHIM (1.5-MM THK) | 12 | |
| 5078776 | 12 FRAME GP-DRAFT | 1 | |
| 1J5929 | 13 BOLT (1-8X6-IN) | 12 | |
| 2993423 | 14 NUT (1-8-THD) | 72 | |
| 5C6565 | 15 BOLT (1/2-13X1.125-IN) | 4 | |
| 5M3062 | 16 BOLT (3/8-16X0.75-IN) | 4 | |
| 6C3241 | 17 BOLT (1/2-13X1.5-IN) | 4 | |
| 1A8537 | 18 BOLT (5/8-11X2.75-IN) | 12 | |
| 6C3213 | 19 BOLT (1-8X4.25-IN) | 72 | |
| 7X0437 | 20 BOLT (1-1/4-7X9.5-IN) | 6 | |
| 7X0451 | 21 NUT-FULL (1-1/4-7-THD) | 6 | |
| 7X0533 | 22 WASHER-HARD (34X55X6-MM THK) | 12 | |
| 8M7145 | 23 WASHER (10.2X28.5X5-MM THK) | 4 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T5361 | 25 WASHER-HARD (28X49X5-MM THK) | 12 | |
| 8T8927 | 26 BOLT (1-8X3.75-IN) | 24 | |
| 3G6076 | 27 SHIM (3.5-MM THK) | 4 |
