System And Components
4T-1829 BOWL GP-SCRAPERS/N 6PC1-493; 4LD1-99999
Group No: 4T-1829
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8W3923 | 1 BOWL AS | 1 | |
| 5C6084 | BLOCK (LH SIDE) | 1 | |
| 6K0942 | BAR (RH SIDE) | 1 | |
| 3G0033 | 2 BRACKET-PIVOT | 2 | |
| 8J5178 | 3 BLOCK | 1 | |
| 8J9893 | 4 SPREADER AS-FRONT | 1 | |
| 9J7342 | BRACKET | 2 | |
| 9J0021 | 5 SUPPORT-EDGE | 1 | |
| 1U1566 | 6 RIB | 1 | |
| 4T5415 | 7 PLATE-WEAR | 2 | |
| 5J3101 | 8 REINFORCEMENT (RH)(R.H.) | 1 | |
| 5J3102 | REINFORCEMENT (LH)(L.H.) | 1 | |
| 9J6998 | 9 PIVOT-DRAFT ARM | 2 | |
| 3J2849 | 10 RIB (RH)(RH) | 1 | |
| 3J2850 | RIB (LH)(LH) | 1 | |
| 3D2365 | 11 CLIP | 10 | |
| 3J8292 | 12 STIFFENER-SIDE | 4 | |
| 3J8345 | 13 STIFFENER-SIDE (RH)(R.H.) | 1 | |
| 3J8346 | STIFFENER-SIDE (LH)(L.H.) | 1 | |
| 8H3390 | 14 NUT-FULL (1-1/2-12-THD) | 4 | |
| 1U3655 | ROD | 2 | |
| 9J6919 | WASHER | 4 | |
| 4T0087 | RETAINER | 4 | |
| 9J7368 | 15 RAIL AS | 2 | |
| 3H4776 | 16 BOSS (3/8-16X1.25-IN) | 1 | |
| 6J1399 | 17 BRACKET | 1 | |
| 7J6009 | 18 BLOCK AS-PUSH | 1 | |
| 1U4216 | PLATE | 1 | |
| 7J6008 | PLATE AS | 1 | |
| 9D1205 | 19 BLOCK | 1 | |
| 7V8984 | 20 BOSS | 3 | |
| 4T5364 | 21 BLOCK | 4 | |
| 9G5742 | 22 BOSS (3/8-16-THD) | 4 | |
| 7J5544 | 23 FITTING (3/4X16-THD) | 4 | |
| 4H9027 | 24 PLUG-PIPE | 1 | |
| 4T0813 | 25 PLATE | 2 | |
| 9G6082 | 26 CAP AS-FILLER | 1 | |
| 8P0408 | CAP-FILLER (FUEL TANK) | 1 | |
| 4B5949 | 27 FILTER ELEMENT-FUEL (FUEL CAP) | 2 | |
| 4B5423 | 28 GASKET | 1 | |
| 7T2037 | 29 GASKET | 1 | |
| 3F4134 | 30 BAFFLE (FUEL TANK FILL CAP) | 1 | |
| 7B2002 | 31 WASHER (10.2X44.5X3-MM THK) | 1 | |
| 3H8389 | 32 SCREW-FILLER CAP | 1 | |
| 6G2514 | 33 BOSS | 16 | |
| 7G4550 | 34 GROMMET | 4 | |
| 4T8899 | 35 BLOCK | 2 | |
| 1U4100 | 36 HOOK-RETRIEVAL | 2 | |
| 4D6267 | 37 BLOCK | 1 | |
| 4V3638 | 38 BOSS | 2 | |
| 8J1196 | 39 LUG (3/8-16-THD) | 1 | |
| 3J3532 | 40 LUG | 1 | |
| 9J6994 | 41 BRACKET AS | 4 | |
| 3J5169 | NUT-WELD (5/8-11-THD) | 1 | |
| 3B2968 | 42 BOLT (3/4-10X3.5-IN) | 4 | |
| 2H3790 | 43 NUT (3/4-10-THD) | 4 | |
| 4T3874 | 44 COVER AS | 1 | |
| 0L1329 | 45 BOLT (1/2-13X3-IN) | 1 | |
| 5P8245 | 46 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8W2083 | 47 PIN AS | 1 | |
| 3J2910 | SPACER (46X73X15-MM THK) | 1 | |
| 8W1708 | 48 PIN | 2 | |
| 2A1538 | 49 BOLT (3/4-10X2.25-IN) | 2 | |
| 4J5193 | 50 PIN | 2 | |
| 4T6604 | 51 PLATE | 2 | |
| 5P3882 | 52 BOLT-LOCKING (3/4-10X2.25-IN) | 2 | |
| 8W3058 | 53 CABLE AS | 1 | |
| 8W1267 | 54 GAUGE-FUEL LEVEL | 1 | |
| 9P7121 | 55 STRAINER-FUEL | 1 | |
| 2Y4071 | 56 PADLOCK (DOMESTIC USE) | 1 | |
| 5P8502 | PADLOCK GP (EXPORT USE) | 1 | |
| 5P8500 | KEY | 2 | |
| 6V5874 | COVER | 1 | |
| 8W3534 | 57 RAIL AS | 1 | |
| 0S1626 | 58 BOLT (3/4-10X1.5-IN) | 8 | |
| 5P8248 | 59 WASHER-HARD (20X36.5X3.5-MM THK) | 18 | |
| 4T8118 | 60 RAIL AS | 1 | |
| 6K0138 | 61 BOLT-LOCKING (5/8-11X1.25-IN) | 4 | |
| 5P8247 | 62 WASHER-HARD (17X32X3.5-MM THK) | 4 |
