System And Components
8W-2209 CONTROL GP-TRANSMISSIONS/N 2PD1011-99999
Group No: 8W-2209
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D0506 | 1 HANDLE | 1 | |
| 5B8407 | PIN | 1 | |
| 6D0679 | 2 KNOB (GEAR SELECT) | 1 | |
| 4V6981 | 3 SCREW-BUTTON HEAD (1/4-20X0.75-IN) | 6 | |
| 5T1153 | 4 LEVER AS (GEAR SELECT) | 1 | |
| 4B4314 | RIVET | 2 | |
| 8W0976 | 5 HOUSING | 1 | |
| 6V8185 | 6 NUT (1/4-20-THD) | 3 | |
| 6G0001 | 7 SHAFT | 1 | |
| 2N3477 | 8 SCREW-MACHINE (6-32X1.25-IN) | 2 | |
| 7D6922 | LOCKNUT (6-32-THD) | 2 | |
| 4B5324 | 9 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 5K0906 | 10 BOLT (5/16-18X0.625-IN) | 2 | |
| 8T9367 | 11 BOLT (1/4-20X2-IN) | 3 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 5 | |
| 6G4092 | 12 BUSHING | 2 | |
| 5T1160 | 13 LEVER AS (NEUTRAL LOCK) | 1 | |
| 5T1187 | 14 PLATE AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 2 | |
| 0325405 | 15 SPRING | 1 | |
| 6G4195 | 16 SWITCH AS-LIMIT (BACK UP ALARM) | 1 | |
| 3L8187 | LOCKWASHER | 1 | |
| 6V8373 | SCREW-MACHINE (6-32X0.187-IN) | 3 | |
| 4B4674 | 17 WASHER (6.4X14.5X1.6-MM THK) | 2 | |
| 8W5857 | 18 CONSOLE-TRANSMISSION | 1 | |
| 8W1229 | 19 PLATE | 1 | |
| 5P4115 | 20 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 8W1228 | 21 BRACKET | 1 | |
| 4K8864 | 22 CLIP (LOOP) | 1 | |
| 8W2179 | 23 HARNESS AS (OPERATOR COMPARTMENT) | 4 | |
| 5B9318 | 24 BALL | 4 | |
| 6G4134 | 25 PIN | 4 | |
| 6G4093 | 26 SPRING | 4 | |
| 9S8001 | 27 PLUG (5/16-24-THD) | 4 | |
| 4J7533 | SEAL-O-RING | 4 | |
| 3L2540 | 28 BOLT-SOCKET HEAD (10-24X0.75-IN) | 2 | |
| 6V7699 | WASHER-HARD (5.5X13X1.6-MM THK) | 2 | |
| 9W0681 | 29 SENSOR GP-POSITION | 1 | |
| 8D2676 | 30 SWITCH AS-TOGGLE (SINGLE POLE)(TRANS HOLD) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 |
