System And Components
129-4410 FRAME GP-DRAFTS/N 7KR1-UP
Group No: 129-4410
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1294411 | 1 FRAME AS | 1 | |
| 4T2189 | 1A BUSHING | 2 | |
| 1592738 | 1B BUSHING | 2 | |
| 5J8118 | 1C BUSHING | 2 | |
| 3G9967 | 1D BUSHING-TERMINAL | 2 | |
| 5J8065 | 1E BUSHING | 2 | |
| 3G9968 | 1F BUSHING-TERMINAL | 2 | |
| 7J3617 | 1G BUSHING | 2 | |
| 1U0138 | 2 PIN AS | 2 | |
| 8T5361 | 4 WASHER-HARD (28X49X5-MM THK) | 156 | |
| 9J0896 | 5 BRACKET AS | 1 | |
| 3J2373 | BUSHING | 1 | |
| 4J9773 | 6 PIN | 1 | |
| 4J9772 | 7 RETAINER | 2 | |
| 5C6565 | 8 BOLT (1/2-13X1.125-IN) | 4 | |
| 7X0437 | 9 BOLT (1-1/4-7X9.5-IN)(1/4-7X241.3MM) | 6 | |
| 7X0533 | 10 WASHER-HARD (34X55X6-MM THK) | 12 | |
| 7X0451 | 11 NUT-FULL (1-1/4-7-THD) | 6 | |
| 8X4913 | 12 ARM AS-DRAFT FRAME | 2 | |
| 3J3532 | 12A LUG | 2 | |
| 4T0538 | 12B BEARING-ARM | 1 | |
| 8X4914 | 12C SPREADER AS | 1 | |
| 5M3062 | 13 BOLT (3/8-16X0.75-IN) | 4 | |
| 8M7145 | 14 WASHER (10.2X28.5X5-MM THK) | 4 | |
| 8T8927 | 15 BOLT (1-8X3.75-IN) | 24 | |
| 8X4916 | 16 PLATE | 2 | |
| 6V8190 | 17 NUT (1-8-THD) | 72 | |
| 3G6077 | 18 SHOE-WEAR | 2 | |
| 3G6076 | 19 SHIM (3.5-MM THK) | 4 | |
| 5P9211 | 20 BOLT (5/8-11X2.75-IN) | 12 | |
| 5P2566 | 21 BOLT (1/2-13X1.5-IN) | 4 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 1U3582 | 23 TRUNNION | 2 | |
| 1J5929 | 24 BOLT (1-8X6-IN) | 12 | |
| 8J4155 | 25 CAP-BEARING | 2 | |
| 7X0410 | 26 BOLT (1-8X4-IN) | 72 |
