System And Components
374-9023 WIRING GP-GRADE CONTROLS/N WTN1-119
Group No: 374-9023
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 20 | |
| 1243019 | 2 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3710659 | 3 SLEEVE-REFLECTIVE | 1 | |
| 3724806 | 4 ANTENNA (GPS) | 1 | |
| 3748783 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3748785 | 6 COVER | 1 | |
| 3748912 | 7 HARNESS AS-CONTROL (LOAD ASSIST) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 7K1181 | STRAP-CABLE | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 8T8737 | PLUG-SEAL | 15 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 1342540 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 3748914 | 8 BRACKET AS | 1 | |
| 4K9230 | NUT-WELD (10-32-THD) | 4 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3748916 | 9 CABLE AS-COAXIAL | 1 | |
| 3749021 | 10 CABLE AS | 1 | |
| 3925485 | 11 RECEIVER GP-SATELLITE | 1 | |
| 0910081 | 12 SPACER (10.5X20X10-MM THK) | 1 | |
| 1305300 | 13 CLIP | 1 | |
| 1325789 | 14 CLIP (LADDER) | 2 | |
| 1566175 | 15 CLIP (LADDER) | 1 | |
| 2379960 | 16 CLIP (LADDER) | 1 | |
| 3445673 | 17 NUT (M6X1-THD) | 5 | |
| 3812621 | 18 MOUNTING-CABLE TIE | 4 | |
| 4P7581 | 19 CLIP (LADDER) | 2 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 22 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4138 | 23 BOLT (M6X1X20-MM) | 1 | |
| 8T4186 | 24 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4195 | 25 BOLT (M10X1.5X30-MM) | 3 | |
| 8T4971 | 26 BOLT (M6X1X30-MM) | 4 | |
| 9X8256 | 27 WASHER (6.6X12X2-MM THK) | 10 |
