System And Components
234-5600 TANK GP-HYDRAULICS/N AGF1092-UP
Group No: 234-5600
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1U1643 | 1 VALVE (HYDRAULIC TANK) | 1 | |
| 1U2827 | 2 GUIDE-VALVE | 1 | |
| 2D4202 | 3 PLATE | 1 | |
| 2J0917 | 4 RETAINER | 1 | |
| 4J1704 | 5 SEAT-VALVE | 1 | |
| 4T8698 | 6 WASHER (12.2X62X3.5-MM THK) | 1 | |
| 5D1911 | 7 COVER-HYDRAULIC CAP | 1 | |
| 5D7927 | 8 STRAINER AS-OIL (HYDRAULIC TANK FILL) | 1 | |
| 5F3488 | END-STRAINER | 1 | |
| 5J2926 | 9 SPRING | 1 | |
| 2462641 | 11 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 6J3795 | 12 SCREEN AS (HYDRAULIC TANK FILL) | 1 | |
| 6P3860 | 13 SPRING | 1 | |
| 7B3039 | 14 SPRING | 1 | |
| 7H1447 | 15 CAP-FILLER (HYDRAULIC TANK) | 1 | |
| 7J0815 | 16 BOLT-FILTER | 1 | |
| 8J8782 | 17 BODY-DRAIN VALVE | 1 | |
| 8J8783 | 18 VALVE-DRAIN (HYDRAULIC TANK DRAIN) | 1 | |
| 8T3298 | 19 SEAL-RECTANGULAR | 1 | |
| 9J7031 | 20 PLUG-DRAIN (HYDRAULIC TANK) | 1 | |
| 9M7394 | 21 LEVER | 1 | |
| 1194885 | 22 SCREEN (HYDRAULIC TANK) | 1 | |
| 1328876 | 23 FILTER ELEMENT AS-OIL (ULTRA HIGH EFFICIENCY)(HYDRAULIC) | 2 | |
| 1605615 | 24 BREATHER (HYDRAULIC TANK) | 1 | |
| 1704732 | 25 GASKET | 1 | |
| 1927128 | 26 BRACKET AS (STEP) | 1 | |
| 1927619 | 27 GAUGE AS-SIGHT (STEERING OIL) | 1 | |
| 1502952 | ADAPTER | 2 | |
| 1735549 | SEAL-O-RING | 4 | |
| 1930248 | 28 PLATE (OIL LEVEL) | 1 | |
| 2058520 | 29 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2375050 | 30 TANK AS-HYDRAULIC | 1 | |
| 2375483 | 31 COVER AS | 1 | |
| 2389479 | 32 TUBE AS | 1 | |
| 2389537 | 33 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 2428226 | 34 BRACKET | 1 | |
| 2482013 | 35 COVER-FILTER | 1 | |
| 1488316 | 36 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488407 | 37 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1503033 | 38 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T0164 | ELBOW | 1 | |
| 1H1200 | 39 PIN-SPRING | 1 | |
| 1L5072 | 40 DOWEL | 1 | |
| 2J7761 | 41 RING-RETAINING | 1 | |
| 3D2824 | 42 SEAL-O-RING | 1 | |
| 4L6454 | 43 BOLT (3/8-16X1-IN) | 2 | |
| 5M2057 | 44 SEAL-O-RING | 1 | |
| 5P8248 | 45 WASHER-HARD (20X36.5X3.5-MM THK) | 1 | |
| 6F4855 | 46 SEAL-O-RING | 1 | |
| 6H9361 | 47 RING-RETAINING | 1 | |
| 6V5839 | 48 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V7744 | 49 LOCKNUT (M10X1.5-THD) | 1 | |
| 7J5925 | 50 PIN-COTTER | 1 | |
| 7X7729 | 51 WASHER (11X25X3-MM THK) | 5 | |
| 8J1665 | 52 SEAL-O-RING | 1 | |
| 8T2275 | 53 BALL | 1 | |
| 8T4121 | 54 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4122 | 55 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4136 | 56 BOLT (M10X1.5X25-MM) | 15 | |
| 8T4195 | 57 BOLT (M10X1.5X30-MM) | 7 | |
| 8T4224 | 58 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4896 | 59 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T4908 | 60 BOLT (M8X1.25X25-MM) | 2 | |
| 9H6454 | 61 GASKET | 1 |
