System And Components
3T-8364 CONTROL GP-TRANSMISSION HYDS/N 3JB638-UP; 3GB1112-UP
Group No: 3T-8364
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1571 | 1 BOLT (3/8-16X1.75-IN) | 6 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 1P8954 | 3 VALVE GP-SELECTOR & PRESS CONT | 1 | |
| 3D4197 | 4 COVER | 1 | |
| 0S0509 | 5 BOLT (3/8-16X0.75-IN) | 2 | |
| 6T4958 | 6 HARNESS AS | 1 | |
| 5B3718 | SEAL-O-RING | 1 | |
| 1D4566 | 7 BOLT (1/2-13X3.5-IN) | 1 | |
| 1F7958 | NUT-FULL (1/2-13-THD) | 1 | |
| 3B4508 | LOCKWASHER | 1 | |
| 4B4280 | WASHER (13.5X27X2.5-MM THK) | 1 | |
| 9S5222 | SPACER (12.73X18.87X26.19-MM THK) | 1 | |
| 5S0899 | 8 DETENT AS | 1 | |
| 1S3206 | 9 BEARING AS-NEEDLE | 2 | |
| 8P4764 | 10 PIN | 1 | |
| 8S0669 | 11 SLEEVE | 1 | |
| 8M5010 | 12 SEAL-O-RING | 2 | |
| 8M8157 | 13 SEAL-O-RING | 2 | |
| 1A2029 | 14 BOLT (3/8-16X1.125-IN) | 3 | |
| 6I9465 | 15 CYLINDER GP-SHIFT | 1 | |
| 2S1381 | 16 SPRING | 1 | |
| 0S1614 | 17 BOLT (1/4-20X0.5-IN) | 2 | |
| 9X2026 | 18 WASHER (6.5X17X1-MM THK) | 2 | |
| 8C9648 | 19 MOUNT-ISOLATION | 4 | |
| 1T0738 | 20 WASHER (8.4X19X1.83-MM THK) | 4 | |
| 9W1398 | 21 BOLT-SPECIAL | 4 | |
| 9G9150 | 22 CLIP | 2 | |
| 0S1588 | 23 BOLT (3/8-16X1.25-IN) | 1 | |
| 8B4037 | 24 WASHER (0.766X1.75X0.083-IN THK) | 2 | |
| 9H0223 | 25 SEAL-LIP TYPE | 2 | |
| 1P8247 | 26 SHAFT | 1 | |
| 8S6377 | 27 PIN-LOCK | 1 | |
| 5S7954 | 28 LEVER AS | 1 | |
| 9S2825 | 29 DOWEL | 1 | |
| 8M8514 | 30 SEAL-O-RING | 6 | |
| 5S3632 | 31 SLEEVE | 3 | |
| 9P2182 | 32 GEAR (33 TEETH) | 1 | |
| 1P8260 | 33 CAMSHAFT | 1 | |
| 7M2082 | 34 GASKET | 1 | |
| 8S5575 | 35 SEAL-LIP TYPE | 1 | |
| 3T0565 | 36 COVER | 1 | |
| 0L1352 | 37 BOLT (3/8-16X3.25-IN) | 4 | |
| 1267895 | 38 SENSOR GP-POSITION | 1 | |
| 6Y8676 | 39 PLATE AS | 1 | |
| 2K3455 | PIN-SPRING | 1 | |
| 7J2036 | SEAL-O-RING | 1 | |
| 2J6356 | 40 RING-RETAINING | 1 |
