System And Components
3T-8364 CONTROL GP-TRANSMISSION HYDS/N 3JB958-958; 3GB1720-1720
Group No: 3T-8364
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T0565 | 1 COVER | 1 | |
| 3D4197 | 2 COVER | 1 | |
| 9W1398 | 3 BOLT-SPECIAL | 4 | |
| 1T0738 | 4 WASHER (8.4X19X1.83-MM THK) | 4 | |
| 0S1614 | 5 BOLT (1/4-20X0.5-IN) | 2 | |
| 7M2082 | 6 GASKET | 1 | |
| 2J6356 | 7 RING-RETAINING | 1 | |
| 1P8954 | 8 VALVE GP-SELECTOR & PRESS CONT | 1 | |
| 1305300 | 9 CLIP | 2 | |
| 8S0669 | 10 SLEEVE | 1 | |
| 8M5010 | 11 SEAL-O-RING | 2 | |
| 8M8157 | 12 SEAL-O-RING | 2 | |
| 1A2029 | 13 BOLT (3/8-16X1.125-IN) | 3 | |
| 0S1588 | 14 BOLT (3/8-16X1.25-IN) | 1 | |
| 2192076 | 15 CYLINDER GP-SHIFT | 1 | |
| 8S9089 | 16 BOLT (1/2-13X4.5-IN) | 1 | |
| 4B4280 | 17 WASHER (13.5X27X2.5-MM THK) | 1 | |
| 9S5222 | 18 SPACER (12.73X18.87X26.19-MM THK) | 1 | |
| 5R7137 | 19 WASHER-SEALING | 1 | |
| 1F7958 | 20 NUT-FULL (1/2-13-THD) | 1 | |
| 5S0899 | 21 DETENT AS | 1 | |
| 1S3206 | 21A BEARING AS-NEEDLE | 2 | |
| 8P4764 | 21B PIN | 1 | |
| 8B4037 | 22 WASHER (0.766X1.75X0.083-IN THK) | 2 | |
| 5S7954 | 23 LEVER AS (TRANSMISSION) | 1 | |
| 9S2825 | 23A DOWEL | 1 | |
| 1P8247 | 24 SHAFT | 1 | |
| 0S1571 | 25 BOLT (3/8-16X1.75-IN) | 6 | |
| 2S1381 | 26 SPRING | 1 | |
| 9H0223 | 27 SEAL-LIP TYPE | 2 | |
| 8S6377 | 28 PIN-LOCK | 1 | |
| 1P8260 | 29 CAMSHAFT | 1 | |
| 8M8514 | 30 SEAL-O-RING | 6 | |
| 5S3632 | 31 SLEEVE | 3 | |
| 5B3718 | 32 SEAL-O-RING | 1 | |
| 1318194 | 33 HARNESS AS-TRANSMISSION | 1 | |
| 5S3657 | RECEPTACLE AS-CONNECTOR (10-PIN) | 1 | |
| 0L1352 | 34 BOLT (3/8-16X3.25-IN) | 4 | |
| 5M2894 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 1315393 | 36 SENSOR GP-POSITION (TRANSMISSION) | 1 | |
| 9P2182 | 37 GEAR (33-TEETH) | 1 | |
| 0S0509 | 38 BOLT (3/8-16X0.75-IN) | 2 | |
| 8S5575 | 39 SEAL-LIP TYPE | 1 | |
| 6Y8676 | 40 PLATE AS | 1 | |
| 2K3455 | PIN-SPRING | 1 | |
| 7J2036 | 41 SEAL-O-RING | 1 | |
| 9X2026 | 42 WASHER (6.5X17X1-MM THK) | 2 | |
| 8C9648 | 43 MOUNT-ISOLATION | 4 | |
| 1K4649 | 46 SPACER (0.516X1X1-IN THK) | 1 | |
| 5P8245 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
