System And Components
464-7883 LINES GP-LIFT CYLINDERS/N P5T1-UP
Group No: 464-7883
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4391867 | 1 ADAPTER AS | 2 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 3796986 | ADAPTER-TEE | 1 | |
| 4753420 | 2 TUBE AS | 1 | |
| 4753421 | 3 TUBE AS | 1 | |
| 4857324 | 4 BRACKET AS | 1 | |
| 4857325 | 5 HOSE AS | 1 | |
| 4857326 | 6 HOSE AS | 1 | |
| 1488347 | 7 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1697409 | 8 UNION AS | 1 | |
| 6V8996 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1772215 | 9 STRAP-DUAL CLAMP | 1 | |
| 1909821 | 10 ELBOW AS | 1 | |
| 6V8989 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 2721882 | 11 STUD-TAPERLOCK (M12X1.75X80-MM) | 2 | |
| 3023908 | 12 SPACER (11X20X30-MM THK) | 2 | |
| 3293356 | 13 NUT (M12X1.75-THD) | 2 | |
| 3445675 | 14 NUT (M10X1.5-THD) | 1 | |
| 5K5338 | 15 CLIP (LOOP) | 1 | |
| 5P7460 | 16 CLIP (SLOT) | 5 | |
| 5P7461 | 17 CLIP (TAB) | 5 | |
| 6V9170 | 18 NUT-BULKHEAD (1-14-THD) | 4 | |
| 6V9831 | 19 CAP (ORFS) | 4 | |
| 7G3832 | 20 GROMMET | 2 | |
| 7G3833 | 21 CLIP (TAB) | 2 | |
| 7G3834 | 22 CLIP (SLOT) | 2 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4194 | 24 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4195 | 25 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 26 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T6466 | 28 BOLT (M10X1.5X60-MM) | 2 |
