System And Components
202-9133 LINES GP-CONNECTINGS/N 4KL3000-UP
Group No: 202-9133
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1428948 | 1 FITTING AS (QUICK DISCONNECT, MALE) | 1 | |
| 1428949 | 2 FITTING AS (QUICK DISCONNECT, FEMALE) | 1 | |
| 1796957 | 3 HOSE AS | 2 | |
| 3D2824 | 4 SEAL-O-RING | 2 | |
| 6V8637 | 5 CONNECTOR | 2 | |
| 6V9746 | 6 SEAL-O-RING | 4 | |
| 7G5984 | 7 CLIP (TAB) | 2 | |
| 7G5985 | 8 CLIP (SLOT) | 2 | |
| 7G5986 | 9 GROMMET | 2 | |
| 7M8485 | 10 SEAL-O-RING | 2 | |
| 8T4149 | 11 ELBOW | 2 | |
| 8T4192 | 12 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 4 |
