System And Components
374-7400 FRAME GP-DRAFTS/N WT61-UP
Group No: 374-7400
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G3606 | 1 SHOE AS-WEAR | 2 | |
| 3J3535 | 2 SHIM (3.4-MM THK) | 8 | |
| 4J9772 | 3 RETAINER | 2 | |
| 4J9849 | 4 PIN | 1 | |
| 7J2652 | 5 RETAINER | 2 | |
| 7J3019 | 6 BRACKET AS | 1 | |
| 3J9511 | 6A BUSHING | 1 | |
| 7J3373 | 7 CAP-BEARING | 2 | |
| 8J7533 | 8 DOOR-DRAFT TUBE | 2 | |
| 8J9669 | 9 YOKE | 2 | |
| 9J6260 | 10 TRUNNION | 2 | |
| 1904241 | 11 BLOCK AS | 4 | |
| 3J2333 | 11A BUSHING | 1 | |
| 3760097 | 12 FRAME AS-DRAFT | 1 | |
| 5J8361 | 12A BUSHING | 1 | |
| 5J8363 | 12B BUSHING | 3 | |
| 7J2603 | 12C BUSHING | 2 | |
| 7J2604 | 12D BUSHING | 2 | |
| 8J9926 | 12E BUSHING | 2 | |
| 9J1140 | 12F BUSHING | 2 | |
| 9J1141 | 12G BUSHING-TERMINAL | 2 | |
| 1A0075 | 13 BOLT (3/4-16X1.75-IN) | 6 | |
| 1J5929 | 14 BOLT (1-8X6-IN) | 8 | |
| 3B7721 | 15 BUSHING-REDUCER | 2 | |
| 3K5234 | 16 WASHER-HARD (28X49X6-MM THK) | 8 | |
| 5M3062 | 17 BOLT (3/8-16X0.75-IN) | 4 | |
| 5P2228 | 18 BOLT (1/2-13X1-IN) | 4 | |
| 6V4432 | 19 BOLT (1/2-13X4-IN) | 6 | |
| 2993436 | 20 BOLT (7/8-9X3.5-IN) | 24 | |
| 7X0393 | 21 BOLT (7/8-9X6.5-IN) | 8 | |
| 7X0432 | 22 BOLT (1-1/4-7X6.5-IN) | 4 | |
| 7X0451 | 23 NUT-FULL (1-1/4-7-THD) | 4 | |
| 7X0533 | 24 WASHER-HARD (34X55X6-MM THK) | 8 | |
| 8C6913 | 25 WASHER-HARD (24X41.5X4-MM THK) | 32 | |
| 8M7145 | 26 WASHER (10.2X28.5X5-MM THK) | 4 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 30 |
