System And Components
4T-7769 FRAME GP-DRAFTS/N 7CB86-90
Group No: 4T-7769
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8W9420 | 1 ARM AS-DRAFT FRAME (RH) | 1 | |
| 9J0002 | 2 BEARING | 1 | |
| 8W9324 | 3 STRIP | 1 | |
| 8W9325 | 4 PLATE | 1 | |
| 8P9770 | 5 PLATE | 1 | |
| 7G4550 | 6 GROMMET | 4 | |
| 5T9660 | 7 LUG | 4 | |
| 8W9244 | 8 PLATE AS (RH) | 1 | |
| 7G4550 | 9 GROMMET | 3 | |
| 8W9421 | 10 ARM AS-DRAFT FRAME (LH) | 1 | |
| 9J0002 | 11 BEARING | 1 | |
| 8W9324 | 12 STRIP | 1 | |
| 8W9325 | 13 PLATE | 1 | |
| 8P9770 | 14 PLATE | 1 | |
| 7G4550 | 15 GROMMET | 4 | |
| 5T9660 | 16 LUG | 4 | |
| 8W9243 | 17 PLATE AS (LH) | 1 | |
| 7G4550 | 18 GROMMET | 3 | |
| 7J3373 | 19 CAP-BEARING | 2 | |
| 8J7533 | 20 DOOR-DRAFT TUBE | 2 | |
| 4T8959 | 21 FRAME AS-DRAFT | 1 | |
| 4T9095 | FRAME AS-DRAFT | 1 | |
| 9J1140 | 22 BUSHING | 2 | |
| 9J1141 | 23 BUSHING-TERMINAL | 2 | |
| 5J8363 | 24 BUSHING | 3 | |
| 8W2849 | BEARING | 3 | |
| 5J8361 | 25 BUSHING | 1 | |
| 8W2852 | BEARING (1.52-MM OS) | 1 | |
| 8J9926 | 26 BUSHING | 2 | |
| 7J2604 | 27 BUSHING | 2 | |
| 1K4620 | 28 BAR | 2 | |
| 7J2603 | 29 BUSHING | 2 | |
| 3Y7829 | 30 BOSS (3/8-16-THD) | 2 | |
| 7J2652 | 31 RETAINER | 2 | |
| 3J3535 | 32 SHIM (3.4-MM THK) | 6 | |
| 3G3606 | 33 SHOE AS-WEAR | 2 | |
| 9J6260 | 34 TRUNNION | 2 | |
| 8J9669 | 35 YOKE | 2 | |
| 3B7721 | 36 BUSHING-REDUCER | 2 | |
| 8J1329 | 37 CLIP | 4 | |
| 2D1683 | 38 FITTING (1/8-27 PTF) | 2 | |
| 4T8886 | 39 HOSE AS | 2 | |
| 3G7752 | 40 PIN AS | 2 | |
| 3G4434 | 41 PIN AS | 2 | |
| 8J1431 | SPRING | 1 | |
| 4J9849 | 42 PIN | 1 | |
| 3K9770 | 43 NUT-FULL (1-1/4-7-THD) | 4 | |
| 4K0684 | 44 WASHER-HARD (34X55X6-MM THK) | 8 | |
| 8X0382 | 45 BLOCK AS | 4 | |
| 3J2333 | 46 BUSHING | 1 | |
| 0S0509 | 47 BOLT (3/8-16X0.75-IN) | 4 | |
| 8M7145 | WASHER (10.2X28.5X5-MM THK) | 4 | |
| 6J1536 | 48 BOLT (7/8-9X6.5-IN) | 8 | |
| 5P8249 | 49 WASHER-HARD (24X41.5X4-MM THK) | 152 | |
| 0S1621 | 50 BOLT (1/2-13X1-IN) | 4 | |
| 4J9772 | RETAINER | 2 | |
| 6H1628 | 51 BOLT (1-1/4-7X6.5-IN) | 4 | |
| 1B2886 | 52 BOLT (1/2-13X3.75-IN) | 6 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 1D4628 | 53 BOLT (7/8-9X3.25-IN) | 24 | |
| 1D4630 | 54 BOLT (7/8-9X4-IN) | 60 | |
| 2J3505 | NUT-FULL (7/8-9-THD) | 60 | |
| 1J5999 | 55 BOLT (1/2-13X1.25-IN) | 4 | |
| 2B4823 | WASHER (13.9X25.4X4-MM THK) | 4 | |
| 9F6936 | 56 BOLT (1-8X6-IN) | 8 | |
| 3K5234 | WASHER-HARD (28X49X6-MM THK) | 8 | |
| 5P8122 | 57 BOLT-LOCKING | 6 | |
| 7J3019 | 58 BRACKET AS | 1 | |
| 3J9511 | BUSHING | 1 |
