5T-4633 WHEEL GP-REARS/N 1BB1-475; 1BB477-503; 1BB505-505; 1BB516-518; 1BB520-520

Group No: 5T-4633
Part NumberPart NameQty
4D48231 STUD-TAPERLOCK (5/8-11-THD)84
6G27382 RETAINER2
8L92413 SEAL-O-RING2
9G53234 SEAL GP-DUO-CONE2
5D62986 CUP-BEARING2
5D6296CONE-BEARING2
4J12537 SEAL-O-RING2
6V44638 BOLT-LOCKING (1/2-13X1.375-IN)16
5P8245WASHER-HARD (13.5X25.5X3-MM THK)16
3D29589 SEAL-O-RING2
6G437110 RING-LOCK2
9D052311 VALVE GP-TIRE2
2G9668HOUSING AS-CORE1
2G9667CAP1
6F3930CORE-VALVE1
6J3134SEAL-O-RING1
4J125512 CAP-HUB2
1A853713 BOLT (5/8-11X2.75-IN)16
5P8247WASHER-HARD (17X32X3.5-MM THK)16
3J879014 RETAINER2
4D5642SHIM PACK (INCLUDES 14-SHIMS)2
3B055115 PLUG-PIPE2
3D294516 FLANGE4
7D286317 BAND-BEAD SEAT2
5T505118 WHEEL AS2
1B517419 PLUG-PIPE2
2G778120 SEALANT
5H952421 SEAL-O-RING2
4D432422 CONE-BEARING2
4D4325CUP-BEARING2
3K036023 SEAL-O-RING2
5T505224 HOUSING AS2
4B9783BALL1
4B8353PIN1
4D725925 STUD-TAPERLOCK (7/8-9-THD)60
2J3505NUT-FULL (7/8-9-THD)60
4D6419WASHER-HARD (24X40X5-MM THK)60
