4T-3971 FRAME GP-DRAFTS/N 1BB1322-1352

Group No: 4T-3971
Part NumberPart NameQty
3G44341 PIN AS2
8J1431SPRING1
4J98492 PIN1
3K97703 NUT-FULL (1-1/4-7-THD)4
4K06844 WASHER-HARD (34X55X6-MM THK)8
8X44545 BLOCK AS4
3J23336 BUSHING1
0S05097 BOLT (3/8-16X0.75-IN)4
8M7145WASHER (10.2X28.5X5-MM THK)4
6J15368 BOLT (7/8-9X6.5-IN)8
5P82499 WASHER-HARD (24X41.5X4-MM THK)152
0S162110 BOLT (1/2-13X1-IN)4
4J9772RETAINER2
6H162811 BOLT (1-1/4-7X6.5-IN)4
5P921112 BOLT (5/8-11X2.75-IN)12
1D462913 BOLT (7/8-9X3.5-IN)24
1D463014 BOLT (7/8-9X4-IN)60
2J3505NUT-FULL (7/8-9-THD)60
1J599915 BOLT (1/2-13X1.25-IN)4
2B4823WASHER (13.9X25.4X4-MM THK)4
9F693616 BOLT (1-8X6-IN)8
3K5234WASHER-HARD (28X49X6-MM THK)8
5P812217 BOLT-LOCKING6
7J301918 BRACKET AS1
3J9511BUSHING1
7J337319 CAP-BEARING2
8J753320 DOOR-DRAFT TUBE2
8X712921 FRAME AS-DRAFT1
8X7130FRAME AS-DRAFT1
9J114022 BUSHING2
9J114123 BUSHING-TERMINAL2
5J836324 BUSHING3
8W2849BEARING3
5J836125 BUSHING1
8W2852BEARING (1.52-MM OS)1
8J992626 BUSHING2
7J260427 BUSHING2
1K462028 BAR2
7J260329 BUSHING2
7J265230 RETAINER2
3G607631 SHIM (3.5-MM THK)8
3G607732 SHOE-WEAR2
9J626033 TRUNNION2
8J966934 YOKE2
3B772135 BUSHING-REDUCER2
8J132936 CLIP4
2D168337 FITTING (1/8-27 PTF)2
4T888638 HOSE AS2
3G775239 PIN AS2
8W931840 ARM AS (RH)1
9J000241 BEARING1
8W924442 PLATE AS (RH)1
7G4550GROMMET3
8P9770PLATE1
5T966043 LUG4
7G455044 GROMMET4
8W932445 STRIP1
8W9325PLATE1
8W931746 ARM AS (LH)1
8W9324STRIP1
8W9325PLATE1
9J000247 BEARING1
8W924348 PLATE AS (LH)1
7G4550GROMMET3
8P9770PLATE1
5T9660LUG4
7G4550GROMMET4
