System And Components
206-4154 LINES GP-OIL -TURBOCHARGERPART OF 254-4444, 266-8497 TURBOCHARGER GP
Group No: 206-4154
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1664985 | 1 HOSE AS | 1 | |
| 1665022 | 2 ELBOW | 2 | |
| 2841210 | 3 TUBE | 2 | |
| 3025876 | 4 BRACKET | 1 | |
| 3025877 | 5 TUBE AS | 2 | |
| 3025878 | 6 BRACKET | 2 | |
| 3125614 | 7 HOSE AS | 1 | |
| 0307972 | 8 ELBOW | 1 | |
| 0307983 | 9 UNION-FLARED | 2 | |
| 0618284 | 10 TEE | 1 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 1 | |
| 0S1591 | 12 BOLT (3/8-16X1.5-IN) | 2 | |
| 1F7958 | 13 NUT-FULL (1/2-13-THD) | 4 | |
| 3E4352 | 14 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 4B3388 | 15 BOLT (5/16-18X1.125-IN) | 4 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P3456 | 17 SEAL-O-RING | 2 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 6V4589 | 19 SEAL-O-RING | 1 | |
| 6V5134 | 20 SEAL-O-RING | 4 | |
| 6V8337 | 21 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 4 | |
| 1077954 | 22 SPACER (10.2X22X8-MM THK) | 2 | |
| 1003237 | 24 GROMMET | 3 | |
| 8C0624 | 25 SEAL-O-RING | 2 | |
| 8T1887 | 26 CLIP (SLOT) | 3 | |
| 8T1888 | 27 CLIP (TAB) | 3 | |
| 9M4584 | 28 CONNECTOR | 1 | |
| 9S8752 | 29 NUT-FULL (3/8-16-THD) | 3 | |
| 9X8873 | 30 BOLT (1/2-13X2.25-IN) | 4 |
