System And Components
9U-1695 DRAWBAR GP-SWINGINGS/N 1HM1-UP
Group No: 9U-1695
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X0347 | 1 BOLT (5/8-11X2.25-IN) | 2 | |
| 3K2889 | LOCKNUT (5/8-11-THD) | 2 | |
| 3F3442 | 2 DOWEL | 1 | |
| 3W6116 | 3 PIN | 1 | |
| 1508766 | 4 LATCH | 2 | |
| 3B2968 | 5 BOLT (3/4-10X3.5-IN) | 4 | |
| 5P8248 | 6 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 1196204 | 7 PLATE | 1 | |
| 9U3817 | 8 PLATE-WEAR (BOTTOM DRAWBAR HAMMER STRAP) | 1 | |
| 1256370 | 9 DRAWBAR AS | 1 | |
| 1354729 | 10 RETAINER AS | 1 | |
| 9B7237 | 11 BOLT (3/8-16X1.25-IN) | 4 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1354730 | 12 PIN (DRAWBAR) | 1 |
