249-4701 FILTER & LINES GP-POWER TRAIN -OUTPUT TRANSFER GEARS/N B1L1-487
Group No: 249-4701
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6U0455 | 1 STRAP | 2 | |
| 6U0456 | 2 STRAP | 1 | |
| 1417722 | 3 HOSE AS | 1 | |
| 1488327 | 4 CONNECTOR AS | 3 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1801694 | 5 HOSE AS | 1 | |
| 1961203 | 6 TEE | 1 | |
| 1965540 | 7 FILTER GP-OIL (HYDRAULIC)(DIFF LOCK, OUTPUT XFR GEAR) | 1 | |
| 2017213 | 8 HOSE AS | 1 | |
| 2339251 | 9 HOSE AS | 1 | |
| 2367928 | 10 TUBE AS | 1 | |
| 2498077 | 11 HOSE AS | 1 | |
| 2502207 | 12 HOSE AS | 1 | |
| 1488347 | 13 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488408 | 14 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1536237 | 15 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1P4578 | 16 FLANGE-HALF | 4 | |
| 3D2824 | 17 SEAL-O-RING | 1 | |
| 4J0520 | 18 SEAL-O-RING | 2 | |
| 4J0522 | 19 SEAL-O-RING | 3 | |
| 5P7468 | 20 CLIP (SLOT) | 3 | |
| 5P7469 | 21 CLIP (TAB) | 3 | |
| 5P7470 | 22 CLIP (SLOT) | 2 | |
| 5P7471 | 23 CLIP (TAB) | 2 | |
| 5P7703 | 24 GROMMET (52-MM ID) | 1 | |
| 5P8182 | 25 GROMMET (46-MM ID) | 1 | |
| 6V1874 | 26 GROMMET (31-MM ID) | 1 | |
| 6V4349 | 27 GROMMET | 2 | |
| 6V9746 | 28 SEAL-O-RING | 1 | |
| 8C3206 | 29 FLANGE-HALF | 2 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 25 | |
| 8T4133 | 31 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 32 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4139 | 33 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4178 | 34 BOLT (M10X1.5X90-MM) | 4 | |
| 8T4186 | 35 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4196 | 36 BOLT (M10X1.5X35-MM) | 10 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4244 | 38 NUT (M12X1.75-THD) | 1 | |
| 8T4956 | 39 BOLT (M12X1.75X35-MM) | 1 | |
| 1984499 | 40 BRACKET | 1 | |
| 8T4195 | 41 BOLT (M10X1.5X30-MM) | 1 |
