System And Components
283-3513 LINES GP-PUMPS/N MMM861-UP; RRR663-UP
Group No: 283-3513
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7238 | 1 VALVE-SHUTOFF (PUMP LINES) | 1 | |
| 3K0360 | 2 SEAL-O-RING | 1 | |
| 2054132 | 3 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 8T0315 | SEAL-O-RING | 1 | |
| 8T8985 | CONNECTOR | 1 | |
| 2567765 | 4 HOSE AS | 1 | |
| 3295347 | 5 TUBE AS | 1 | |
| 9C2413 | 6 HOSE AS | 1 | |
| 2618505 | 7 TUBE AS | 1 | |
| 2639720 | 8 TUBE AS | 1 | |
| 2681507 | 9 CONNECTOR AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T0315 | SEAL-O-RING | 1 | |
| 2681506 | CONNECTOR | 1 | |
| 2777091 | 10 TUBE AS | 1 | |
| 2833515 | 11 TUBE AS | 1 | |
| 2833516 | 12 HOSE AS | 1 | |
| 2941066 | 14 HOSE AS | 1 | |
| 3631761 | 15 TUBE AS | 1 | |
| 1488327 | 16 CONNECTOR AS | 3 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488336 | 17 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488347 | 18 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488367 | 19 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488374 | 20 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8723 | ELBOW | 1 | |
| 4H7655 | 24 CLAMP-TUBE | 4 | |
| 5P9297 | 25 CLIP (LOOP) | 4 | |
| 6V8397 | 26 SEAL-O-RING | 4 | |
| 6V9746 | 28 SEAL-O-RING | 4 | |
| 8M2773 | 30 CLIP (LOOP) | 2 | |
| 8T1887 | 31 CLIP (SLOT) | 2 | |
| 8T1888 | 32 CLIP (TAB) | 2 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4136 | 34 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 35 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4191 | 36 BOLT (M10X1.5X16-MM) | 1 | |
| 3087677 | 37 CONNECTOR-FILTER | 1 | |
| 3036597 | 38 TUBE AS | 1 | |
| 1963940 | 39 HOSE AS | 1 | |
| 3J1907 | 40 SEAL-O-RING | 1 |
