System And Components
347-8769 SEAT GP-SUSPENSION -FABRIC, HEATEDS/N L4E1-UP
Group No: 347-8769
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1115042 | 1 FASTENER | 3 | |
| 1134036 | 2 CLIP | 6 | |
| 1641250 | 3 HANDLE | 1 | |
| 1641269 | 4 BOOT | 1 | |
| 1641271 | 5 SPRING | 2 | |
| 1641272 | 6 ROD AS | 1 | |
| 1641273 | 7 SPRING-EXTENSION | 2 | |
| 1641274 | 8 BLOCK | 2 | |
| 1641276 | 9 TUBE | 2 | |
| 1641277 | 10 CLIP-SPRING | 2 | |
| 1805787 | 11 KNOB | 1 | |
| 1805788 | 12 BLOCK | 1 | |
| 1805791 | 13 SUPPORT AS-SEAT (LUMBAR) | 1 | |
| 1959223 | 14 SCREW-PAN HEAD (10-14X0.63-IN) | 6 | |
| 2600028 | 15 LEVER-TILT (BOTTOM) | 1 | |
| 3483684 | 16 PAN GP-SEAT (DELUXE) | 1 | |
| 3483688 | 17 ARMREST GP (RH) | 1 | |
| 3488933 | 18 CUSHION AS-BACK | 1 | |
| 3488934 | 19 CUSHION AS-SEAT | 1 | |
| 3494002 | 20 ARMREST GP (LH) | 1 | |
| 3494958 | 21 HANDLE AS | 1 | |
| 3507593 | 22 HEADREST AS-SEAT | 1 | |
| 2P7864 | 23 SCREW-TAPPING (1/4-14-THD) | 2 | |
| 4H1641 | 24 PIN-SPRING | 2 | |
| 6C3677 | 25 RIVET-POP | 2 | |
| 1568315 | 26 SCREW-PAN HEAD (10-16X0.5-IN) | 4 | |
| 9X8256 | 27 WASHER (6.6X12X2-MM THK) | 4 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 8 |
