System And Components
398-6131 AIR CONDITIONER & MOUNTING GPS/N TFJ1-UP
Group No: 398-6131 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1648473 | 1 LOUVER AS-VENT | 1 | |
| 1705337 | 2 GASKET | 1 | |
| 1705338 | 3 GASKET | 2 | |
| 4979406 | 4 GASKET | 1 | |
| 1705342 | 5 COVER | 1 | |
| 1714047 | 6 LOUVER AS-VENT | 1 | |
| 1859464 | 7 LATCH AS (COMPARTMENT) | 3 | |
| 2686704 | 8 FILTER ELEMENT-CAB AIR (AIR CONDITIONER) | 1 | |
| 3270282 | 10 SEAL-INTEGRAL (1/2-IN) | 1 | |
| 3270283 | 11 SEAL-INTEGRAL (3/4-IN) | 1 | |
| 3298940 | 12 AIR CONDITIONER GP | 1 | |
| 3407390 | 13 DUCT | 1 | |
| 3407391 | 14 DUCT | 1 | |
| 3442596 | 15 GASKET | 2 | |
| 1042091 | 16 SCREW-FLAT HEAD (6-20X0.5-IN) | 4 | |
| 1045604 | 17 WASHER (7.2X25X2-MM THK) | 4 | |
| 1185619 | 18 SCREW-FLAT HEAD (6-20X1-IN) | 2 | |
| 1757141 | 19 NUT-HEX FLANGE (M10X1.5-THD) | 6 | |
| 3442595 | 20 GASKET | 2 | |
| 6V7357 | 21 BOLT (M6X1X25-MM) | 2 | |
| 7X2533 | 22 BOLT (M6X1X35-MM) | 2 | |
| 7X2619 | 23 BOLT (M6X1X10-MM) | 2 | |
| 8T7004 | 24 STUD-TAPERLOCK (M10X1.5X35-MM) | 6 | |
| 9X2044 | 25 SCREW-TRUSS HEAD (M6X1X16-MM) | 4 | |
| 9X8256 | 26 WASHER (6.6X12X2-MM THK) | 2 |
