204-6925 FRAME GP-EJECTOR -LHS/N B1W1-UP

Group No: 204-6925
Part NumberPart NameQty
3B84891 FITTING-GREASE (1/8-27 PTF)2
5U71512 CAP-GREASE2
16871233 WASHER (33X63X14-MM THK)4
17166454 WASHER (33X63X5-MM THK)6
17800695 SPACER (8-MM THK)2
17800706 SPACER (5-MM THK)2
18348397 SPACER (3-MM THK)2
18348408 WASHER (33X63X3-MM THK)3
18568549 ROLLER GP-EJECTOR (RH)2
203101710 ROLLER GP-EJECTOR (LH)2
204692711 FRAME GP-EJECTOR (LH)1
204693312 BOSS1
205141513 RING-LOCKING2
205202214 PLATE2
214461515 SCRAPER2
214461716 PLATE-END2
7X255417 BOLT (M16X2X70-MM)8
8C872218 NUT (M30X3.5-THD)2
8T412119 WASHER-HARD (11X21X2.5-MM THK)4
8T413320 NUT (M10X1.5-THD)4
8T419621 BOLT (M10X1.5X35-MM)4
8T422322 WASHER-HARD (13.5X25.5X3-MM THK)6
8T495623 BOLT (M12X1.75X35-MM)6
8T500524 BOLT (M10X1.5X70-MM)4
8T662425 BOLT (M30X3.5X180-MM)2
9X615126 BOLT (M30X3.5X240-MM)2
9X825727 WASHER (17.5X30X3.5-MM THK)8
9X825828 WASHER (33X56X6-MM THK)6
215893729 BOSS1
