System And Components
356-4664 DIFFERENTIAL & BEVEL GEAR GP -AXLE, REARS/N L4E1-UP
Group No: 356-4664
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1J2860 | 1 CUP-BEARING (TAPERED ROLLER) | 1 | |
| 2D9454 | 2 CUP-BEARING | 1 | |
| 2D9455 | 3 CONE-BEARING | 1 | |
| 3F5792 | 4 SEAL-O-RING | 1 | |
| 3S1374 | 5 SPRING | 3 | |
| 5P9505 | 6 CONE-BEARING | 1 | |
| 8S9075 | 7 CONE-BEARING | 2 | |
| 8S9076 | 8 CUP-BEARING | 2 | |
| 1271960 | 9 SCREW-FLAT HEAD (M6X1X16-MM) | 8 | |
| 1381490 | 10 SPACER (10.2X18X15-MM THK) | 3 | |
| 1383624 | 11 RING | 2 | |
| 1383626 | 12 LOCK | 2 | |
| 1383638 | 13 HUB | 1 | |
| 1384096 | 14 SHIM (0.05-MM THK) | 5 | |
| 1384097 | 15 SHIM (0.08-MM THK) | 5 | |
| 1384098 | 16 SHIM (0.12-MM THK) | 3 | |
| 1384099 | 17 SHIM (0.5-MM THK) | 1 | |
| 1437605 | 18 RETAINER | 1 | |
| 3619411 | 19 GEAR SET-BEVEL | 1 | |
| 1477381 | 20 CAGE | 1 | |
| 1518281 | 21 PLATE | 1 | |
| 1518282 | 22 PLATE | 5 | |
| 1518397 | 23 PLATE | 1 | |
| 4456671 | 24 HOUSING-PISTON | 1 | |
| 2242323 | 25 BEARING-THRUST | 2 | |
| 2584467 | 26 HUB AS | 1 | |
| 1520809 | DOWEL | 7 | |
| 1518108 | DOWEL | 3 | |
| 2934503 | 27 SEAL-LIP TYPE | 1 | |
| 2969950 | 28 LOCKNUT AS | 1 | |
| 5L4753 | RING-RETAINING | 1 | |
| 3201132 | 29 CARRIER GP-DIFFERENTIAL (AXLE, REAR) | 1 | |
| 3201136 | 30 SHROUD | 1 | |
| 3236203 | 31 DIFFERENTIAL GP | 1 | |
| 3334636 | 32 GEAR-SENSOR (40-TEETH) | 1 | |
| 3334637 | 33 GEAR-SENSOR (40-TEETH) | 1 | |
| 3558796 | 34 PISTON | 1 | |
| 3558990 | 35 DISC-FRICTION | 5 | |
| 3559368 | 36 SEAL-D-RING | 1 | |
| 3559369 | 37 SEAL-D-RING | 1 | |
| 3561825 | 38 TUBE | 1 | |
| 3562456 | 39 SEAL-O-RING | 2 | |
| 3595159 | 40 SENSOR & MTG GP-SPEED (WHEEL SPEED) | 1 | |
| 2987137 | 42 BOLT (M16X2X50-MM) | 28 | |
| 1713010 | 43 WASHER-HARD (17.5X32X7-MM THK) | 28 | |
| 3E8025 | 44 BOLT-SOCKET HEAD (M8X1.25X50-MM) | 4 | |
| 8C3210 | 45 BOLT (M6X1X16-MM) | 4 | |
| 7X7729 | 46 WASHER (11X25X3-MM THK) | 3 | |
| 8C3347 | 47 PIN-ROLL | 2 | |
| 8T4121 | 48 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4195 | 49 BOLT (M10X1.5X30-MM) | 19 | |
| 8T4223 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T5412 | 52 BOLT (M12X1.75X140-MM) | 4 | |
| 9F1399 | 53 SEAL-O-RING | 1 | |
| 4448152 | 54 WASHER-THRUST | 1 |
