System And Components
538-3760 FRAME GP-REARS/N 3T81-UP
Group No: 538-3760
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1420050 | 1 BUSHING | 2 | |
| 1625516 | 2 BUSHING | 2 | |
| 1625517 | 3 SEAL | 2 | |
| 1625518 | 4 RING-RETAINING | 2 | |
| 1945012 | 5 DEFLECTOR | 1 | |
| 3808803 | 6 NUT-INSERT (M10X1.5-THD) | 4 | |
| 4168756 | 7 LINK GP-STEERING FRAME LOCK | 1 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4910 | BOLT (M12X1.75X60-MM) | 4 | |
| 2365879 | PLATE AS | 4 | |
| 4545120 | 8 CLAMP AS | 1 | |
| 1951106 | LOCK-SCREW | 1 | |
| 1951107 | BAND-PERFORATED | 3 | |
| 4572688 | 9 PLATE AS | 1 | |
| 5422397 | 10 FRAME GP-REAR | 1 | |
| 7T1099 | LINK | 10 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4186 | 12 BOLT (M10X1.5X40-MM) | 4 |
