System And Components
238-3240 PANEL GP-CIRCUIT BREAKERS/N WWC1-UP
Group No: 238-3240
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N0718 | 1 SWITCH GP-DISCONNECT | 1 | |
| 3E5169 | 2 GUARD-SWITCH | 1 | |
| 3S2093 | 3 STRAP-CABLE | 12 | |
| 4D1836 | 4 SWITCH-TOGGLE (ENGINE SHUTDOWN) | 1 | |
| 6T3644 | 5 CIRCUIT BREAKER AS (20-AMPERE)(MAIN) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 7U4891 | 6 SCREW (10-32X1-IN) | 4 | |
| 7V9275 | 7 STRAP | 1 | |
| 8S2634 | 8 COVER AS | 1 | |
| 8S4211 | 9 PLATE | 2 | |
| 9S4693 | 10 CIRCUIT BREAKER AS (80-AMPERE)(ALTERNATOR) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 7X3182 | BOLT (1/4-28X0.5-IN) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 0S1570 | BOLT (1/4-28X0.625-IN) | 2 | |
| 1227052 | 11 SPACER (10.5X20X28-MM THK) | 1 | |
| 1460240 | 12 SWITCH GP-TOGGLE (LOCKING)(HOOD LOCKING) | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3633 | RING-LOCKING | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1865858 | 13 PLATE | 1 | |
| 1937317 | 14 RECEPTACLE AS-AUXILIARY START | 1 | |
| 4N6579 | RECEPTACLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 5P0747 | CABLE (00-GA, BLACK)(272-CM) | ||
| 5P0761 | CABLE (00-GA, RED)(269-CM) | ||
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 2383239 | 15 PLATE AS | 1 | |
| 3256957 | 16 HARNESS AS-PANEL (CIRCUIT BREAKER) | 1 | |
| 7K0899 | GROMMET | 1 | |
| 8N1523 | LOCKWASHER | 1 | |
| 8N1540 | PIN-CONNECTOR (12-GA TO 14-GA) | 2 | |
| 8N1542 | PIN-CONNECTOR (10-GA) | 1 | |
| 8N1544 | PIN-CONNECTOR (8-GA) | 2 | |
| 8N1548 | PIN-CONNECTOR (4-GA) | 1 | |
| 9X6856 | PIN-CONNECTOR (16-GA TO 18-GA) | 9 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 7G7917 | PLUG-SEAL | 8 | |
| 7G7918 | PLUG-SEAL | 1 | |
| 7G7920 | PLUG-SEAL | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 8N1517 | RECEPTACLE AS-CONNECTOR (25-PIN) | 1 | |
| 8N1522 | NUT (2-1/4-16-THD) | 1 | |
| 1148843 | SLEEVE-PLASTIC (20-CM) | ||
| 1863736 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 7 | |
| 9X6772 | STRAP-CABLE | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 9G4344 | TERMINAL-RING (4-GA, 1/2-IN SCREW) | 1 | |
| 2L8067 | TERMINAL-RING (10-GA TO 12-GA, 1/4-IN SCREW) | 1 | |
| 2L8074 | TERMINAL-RING (14-GA TO 16-GA, NO. 6 SCREW) | 3 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 2 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1284190 | TERMINAL AS | 2 | |
| 6H3586 | TERMINAL-RING (6-GA TO 8-GA, 1/4-IN SCREW)(4-CM) | ||
| 6V9023 | TUBE-HEAT SHRINK (12.7-MM DIA) | 1 | |
| 4L6454 | 17 BOLT (3/8-16X1-IN) | 4 | |
| 4P7581 | 18 CLIP (LADDER) | 3 | |
| 4P8134 | 19 CLIP (LADDER) | 3 | |
| 2636342 | 20 CLIP | 8 | |
| 7U4892 | 21 SCREW (8-32X0.75-IN) | 2 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 23 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4185 | 24 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4896 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 2743774 | 26 CAP-CONNECTOR | 1 |
