System And Components
397-6384 FRAME GP-REAR SUSPENSIONS/N TFJ1-UP
Group No: 397-6384 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1245529 | 1 DOWEL | 2 | |
| 5548864 | 2 PIN-SUSPENSION | 1 | |
| 1550198 | 3 WASHER (26X100X25-MM THK) | 1 | |
| 1550385 | 4 RING-CLAMP | 1 | |
| 1553537 | 5 BEARING | 1 | |
| 1808517 | 6 BRACKET-STABILIZER | 1 | |
| 3532230 | 7 ROD AS | 1 | |
| 3518204 | 7A BUSHING | 2 | |
| 1783313 | ROD | 1 | |
| 5639045 | 8 FRAME AS (REAR) | 1 | |
| 1669314 | 9 BOLT (M24X3X340-MM) | 6 | |
| 1984771 | 10 WASHER-HARD (26X47X12-MM THK) | 6 | |
| 6V8237 | 11 WASHER (26X44X4-MM THK) | 10 | |
| 7X0851 | 12 NUT (M24X3-THD) | 5 | |
| 7X2563 | 13 BOLT (M20X2.5X60-MM) | 8 | |
| 8T0364 | 14 BOLT (M24X3X220-MM) | 4 | |
| 8T0367 | 15 BOLT (M24X3X260-MM) | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4123 | 17 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T4195 | 18 BOLT (M10X1.5X30-MM) | 6 | |
| 8T5397 | 19 BOLT (M24X3X280-MM) | 6 | |
| 8T1482 | 20 WASHER-HARD (26X50X8-MM THK) | 6 |
