375-2568 LINES GP-HYDRAULIC FAN -RADIATORS/N L4E1-1899
Group No: 375-2568
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1488430 | 1 TEE AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7X0873 | TEE | 1 | |
| 1757716 | 2 HOSE AS | 1 | |
| 2309802 | 3 HOSE AS | 1 | |
| 3482302 | 4 VALVE GP-SOLENOID (HYDRAULIC FAN MOTOR) | 1 | |
| 2796530 | VALVE GP-SOLENOID (HYDRAULIC FAN) | 1 | |
| 2616728 | COIL AS (10-VOLT) | 1 | |
| 3752549 | 5 HOSE AS | 1 | |
| 3752550 | 6 HOSE AS | 1 | |
| 3752551 | 7 TUBE AS | 1 | |
| 3752552 | 8 PLATE | 1 | |
| 3752553 | 9 PLATE | 1 | |
| 3754528 | 10 BRACKET | 1 | |
| 1189573 | 11 BOLT-12 POINT HEAD (M10X1.5X35-MM) | 8 | |
| 1488347 | 12 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488455 | 13 UNION AS | 1 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1645574 | 14 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8784 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1882008 | 15 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T7970 | ELBOW | 1 | |
| 1889644 | 16 SCREW-FLAT HEAD (M8X1.25X25-MM) | 2 | |
| 1984776 | 17 WASHER-HARD (8.8X20X8-MM THK) | 2 | |
| 2501488 | 18 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 3 | |
| 1547159 | TEE | 1 | |
| 2P1293 | 19 LOCKNUT (1-3/16-12-THD) | 1 | |
| 4J0520 | 20 SEAL-O-RING | 1 | |
| 4J5267 | 21 SEAL-O-RING | 1 | |
| 5C7261 | 22 NUT (M8X1.25-THD) | 4 | |
| 6V9172 | 23 NUT (1-7/16-12-THD) | 1 | |
| 7X0579 | 24 WASHER-HARD (8.8X25.5X2-MM THK) | 2 | |
| 7X0818 | 25 BOLT (M8X1.25X45-MM) | 2 | |
| 8C3205 | 26 FLANGE-HALF | 2 | |
| 8C3206 | 27 FLANGE-HALF | 2 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4896 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T6870 | 30 BOLT (M8X1.25X70-MM) | 2 | |
| 8T9655 | 31 MOUNT-ISOLATION | 4 | |
| 8T9658 | 32 SPACER (8.2X12.7X25.4-MM THK) | 2 |
