System And Components
115-9184 TANK GP-FUELS/N 5RK26-UP
Group No: 115-9184
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G0244 | 1 GAUGE GP-FUEL LEVEL | 1 | |
| 7V6480 | SCREW-PAN HEAD (6-32X6.35-MM) | 2 | |
| 3E7753 | 2 FLOAT AS | 1 | |
| 5D5654 | 3 MOUNTING | 4 | |
| 6G5294 | 5 CAP | 2 | |
| 7T2036 | 6 CAP AS-FILLER (FUEL) | 1 | |
| 3F4134 | 6A BAFFLE (FUEL TANK FILL CAP) | 1 | |
| 4B5949 | 6B FILTER ELEMENT-FUEL (FUEL CAP)(FUEL CAP) | 1 | |
| 4B5423 | 6C GASKET | 1 | |
| 7T2037 | 6D GASKET | 1 | |
| 7B2002 | 6E WASHER (10.2X44.5X3-MM THK) | 1 | |
| 7T2009 | 6F VALVE AS (FUEL CAP) | 1 | |
| 4B1663 | 6G FILTER ELEMENT-FUEL (FUEL CAP)(FUEL CAP) | 1 | |
| 8P0408 | CAP-FILLER (FUEL TANK) | 1 | |
| 8W3602 | 7 DEFLECTOR | 1 | |
| 8X2232 | 8 SHIM PACK (INCLUDES 8-SHIMS) | 4 | |
| 9D0630 | 9 CAP-DUST | 1 | |
| 9D9438 | 10 WASHER (21X111X10-MM THK) | 4 | |
| 9M0164 | 11 CLAMP-HOSE | 1 | |
| 9M7958 | 12 CLAMP-HOSE | 1 | |
| 9P7121 | 13 STRAINER-FUEL (TANK) | 1 | |
| 1050381 | 14 BLOCK | 1 | |
| 1162041 | 15 GUARD | 1 | |
| 1249325 | 16 SENSOR GP-FUEL LEVEL | 1 | |
| 1366202 | 17 BREATHER AS (FUEL TANK) | 1 | |
| 1452817 | 18 HOSE AS | 1 | |
| 1516225 | 19 SPACER (50-MM THK) | 2 | |
| 1562618 | 20 TANK AS-FUEL | 1 | |
| 3008495 | 21 RECEIVER (FAST FILL FUEL) | 1 | |
| 1488373 | 22 ELBOW AS | 1 | |
| 8C3364 | ELBOW | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1D4620 | 23 BOLT (3/4-10X7-IN) | 2 | |
| 4L6454 | 24 BOLT (3/8-16X1-IN) | 11 | |
| 5P6712 | 25 BOLT-LOCKING (3/4-10X3-IN) | 4 | |
| 5P8248 | 26 WASHER-HARD (20X36.5X3.5-MM THK) | 6 | |
| 6G7803 | 27 VENT AS (FUEL TANK) | 1 | |
| 6V5051 | 28 SEAL-O-RING | 1 | |
| 6V8801 | 29 NUT (3/8-16-THD) | 5 | |
| 8T2501 | 30 BOLT (3/8-16X2-IN) | 4 | |
| 8T2561 | 31 WASHER-HARD (10.5X28.5X5-MM THK) | 5 | |
| 8T4896 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 8T9101 | 33 BOLT (3/8-16X2.75-IN) | 2 | |
| 5T8645 | KIT-VENT (FUEL TANK)(ALUMINUM) | 1 | |
| 2721595 | KIT-VENT (FUEL TANK)(PLASTIC) | 1 |
