System And Components
460-6670 CONTROL GP-SERVICE BRAKES/N KDZ1-UP
Group No: 460-6670
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D0193 | 1 CONNECTOR-PIPE | 2 | |
| 2D7325 | 2 TEE-PIPE | 6 | |
| 2G8815 | 3 VALVE GP-RELIEF | 1 | |
| 2H3940 | 4 ELBOW | 1 | |
| 3D6370 | 5 ELBOW | 3 | |
| 3D7587 | 6 ELBOW | 7 | |
| 4D6243 | 7 HOSE AS | 1 | |
| 4H6112 | 8 BREATHER (SERVICE BRAKE) | 1 | |
| 4H6147 | 9 CONNECTOR | 12 | |
| 4J6303 | 10 TAG-IDENTIFICATION (NUMBER THREE) | 2 | |
| 4J6305 | 11 TAG-IDENTIFICATION (NUMBER FIVE) | 2 | |
| 4J6308 | 12 TAG-IDENTIFICATION (NUMBER EIGHT) | 2 | |
| 4S7560 | 13 HOSE AS | 1 | |
| 4S7561 | 14 HOSE AS | 1 | |
| 4S7563 | 15 HOSE AS | 1 | |
| 4S7577 | 16 HOSE AS | 2 | |
| 6D1432 | 17 VALVE-CHECK | 1 | |
| 6D3781 | 18 VALVE GP-CHECK | 2 | |
| 6D8079 | 19 HOSE AS | 1 | |
| 6D9855 | 20 HOSE AS | 1 | |
| 7D4922 | 21 HOSE AS | 1 | |
| 7D6096 | 22 HOSE AS | 2 | |
| 7K1181 | 23 STRAP-CABLE | 11 | |
| 8D9423 | 24 COUPLING | 1 | |
| 8W0703 | 25 HOSE AS | 1 | |
| 8W6908 | 26 VALVE | 1 | |
| 9D3351 | 27 ELBOW | 1 | |
| 0045933 | 28 TEE-PIPE | 2 | |
| 1284972 | 29 VALVE GP-AIR CONTROL | 1 | |
| 1402707 | 30 PLATE AS | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 3 | |
| 1538339 | 31 GASKET | 1 | |
| 1652138 | 32 CONNECTOR | 3 | |
| 1726232 | 33 VALVE GP (SECONDARY BRAKE) | 1 | |
| 1844648 | 34 HOSE AS | 1 | |
| 2471292 | 35 VALVE GP-AIR CONTROL (SERVICE BRAKE PEDAL) | 1 | |
| 2471293 | 36 VALVE GP-AIR CONTROL (SECONDARY BRAKE PEDAL) | 1 | |
| 3510524 | 37 VALVE GP-AIR CONTROL (MANUAL RETARDER) | 1 | |
| 4706126 | 38 PLATE | 1 | |
| 4801472 | 39 FILM-IDENTIFICATION (BRAKE) | 1 | |
| 3680571 | 40 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 3B7722 | 41 BUSHING-PIPE | 1 | |
| 3D8884 | 42 ELBOW | 1 | |
| 3S9175 | 43 ELBOW | 1 | |
| 4D0582 | 44 ELBOW | 1 | |
| 4D5239 | 45 BOLT-12 POINT HEAD (3/8-16X1.625-IN) | 2 | |
| 4D5243 | 46 LOCKWASHER | 2 | |
| 4D6463 | 47 CLIP | 1 | |
| 4J3914 | 48 ELBOW | 1 | |
| 4M0061 | 49 BOLT (5/16-18X0.75-IN) | 8 | |
| 4M5317 | 50 BUSHING-REDUCER | 1 | |
| 5H4778 | 51 ELBOW | 4 | |
| 5K8451 | 52 CLIP (LOOP) | 1 | |
| 5M3062 | 53 BOLT (3/8-16X0.75-IN) | 8 | |
| 5P4424 | 54 ELBOW-AIR BRAKE | 2 | |
| 5S7379 | 55 BOLT (3/8-16X0.875-IN) | 2 | |
| 6B5072 | 56 ADAPTER | 1 | |
| 6V3265 | 57 CLIP | 1 | |
| 7D4903 | 58 ADAPTER | 1 | |
| 7J8611 | 59 ELBOW-PIPE | 2 | |
| 7S4244 | 60 CLIP | 1 | |
| 7X0264 | 61 BOLT (1/4-20X2.5-IN) | 2 | |
| 8T4205 | 62 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4224 | 63 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 8T4896 | 64 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8T6762 | 65 PLUG-PIPE (1/2-14-THD) | 5 | |
| 8T6763 | 66 PLUG-PIPE (1/4-18-THD) | 1 | |
| 8T6765 | 67 PLUG-PIPE (1/4-18-THD) | 1 | |
| 8T9043 | 68 BOLT (5/16-18X0.875-IN) | 2 | |
| 8T9394 | 69 BOLT-SOCKET HEAD (10-24X0.5-IN) | 2 | |
| 9M8406 | 70 CLIP (LOOP) | 1 | |
| 9M8662 | 71 COUPLING | 5 | |
| 5P6007 | 72 TUBE (0.3-M) | ||
| 5P6007 | 72A TUBE (1.3-M EACH) | ||
| 1977484 | KIT-VALVE (BRAKE) | 1 |
