113-0737 LINES GP-AIR CONDITIONERS/N 6KR1-123

Group No: 113-0737

Part Number	Part Name	Qty
1098850	1 HOSE AS	1
7X1806	COUPLING (90-DEG)	2
9X2389	HOSE (52.36IN)
9X7381	2 SEAL-O-RING	2
1093587	3 HOSE AS	1
7X1811	COUPLING (45-DEG)	1
9X4000	COUPLING (90-DEG)	1
9X2390	HOSE (39.37IN)
5M3062	4 BOLT (3/8-16X0.75-IN)	3
8T4896	5 WASHER-HARD (10.2X18.5X2.5-MM THK)	7
1028639	6 BRACKET	1
3E4054	7 FITTING AS-AIR CONDITIONER	1
3E4051	CAP-SEAL (LOW SIDE CHARGE PORT)	1
3E4057	VALVE AS (REFRIGERANT, LOW SIDE)	1
9X7385	8 SEAL-O-RING	2
3E4053	9 FITTING AS-AIR CONDITIONER	1
3E4052	CAP-SEAL (HIGH SIDE CHARGE PORT)	1
3E4058	VALVE AS (REFRIGERANT, HIGH SIDE)	1
6D1641	10 CLIP (LOOP)	1
9X7383	11 SEAL-O-RING	2
9M8406	12 CLIP (LOOP)	1
9X7382	13 SEAL-O-RING	1
9B7237	14 BOLT (3/8-16X1.25-IN)	2
9X7380	15 SEAL-O-RING	2
3E3535	16 DRYER AS-REFRIGERANT (IN-LINE)	1
8S6109	17 CLIP (SLOT)	1
8S6110	18 CLIP (TAB)	1
1145333	19 SWITCH AS-PRESSURE (COMPRESSOR)	1
3E3365	WEDGE-RECEPTACLE LOCK (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	1
1308554	20 HOSE AS	1
7X1803	COUPLING (90-DEG)	2
9X2388	HOSE (18.5IN)
1P6356	21 PLATE	1
8T6466	22 BOLT (M10X1.5X60-MM)	1
8T7934	23 WASHER-HARD (11X21X5-MM THK)	1
3S8664	24 CLIP	2
1036100	25 FITTING AS-AIR CONDITIONER (QUICK DISCONNECT)	1
5P4107	26 LOCKWASHER	1
5P4106	27 NUT (1-7/16-16-THD)	1
6V8801	28 NUT (3/8-16-THD)	2
9X7378	29 SEAL-O-RING	1
4P7581	30 CLIP (LADDER)	2
5P3928	31 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
9X7384	32 SEAL-O-RING	1
1093586	33 HOSE AS	1
7X1814	COUPLING (90-DEG)	1
9X4006	COUPLING-STRAIGHT	1
9X2390	HOSE (21.65IN)
1018789	34 ACCUMULATOR-REFRIGERANT	1
6V3582	35 CLAMP-HOSE	2
1097410	36 BRACKET AS	1
5K8451	37 CLIP (LOOP)	1
1140061	38 PLATE-INSTRUCTION (NO SERVICE-READ OMM)	1
3S2093	39 STRAP-CABLE	4
1068704	40 SUPPRESSOR AS-ARC	1
3E3365	WEDGE-RECEPTACLE LOCK (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
1028802	KIT-RECEPTACLE (2-PIN)	1
