System And Components
133-3419 TANK GP-FUEL -3790-L (1001-US GAL)S/N 2BW1285-UP
Group No: 133-3419
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G0244 | 1 GAUGE GP-FUEL LEVEL (TANK) | 1 | |
| 7V6480 | SCREW-PAN HEAD (6-32X6.35-MM) | 2 | |
| 3E7753 | 2 FLOAT AS | 1 | |
| 5D5654 | 3 MOUNTING | 6 | |
| 6G5294 | 4 CAP | 2 | |
| 6G7803 | 5 VENT AS | 1 | |
| 8W3602 | 6 DEFLECTOR | 1 | |
| 8X2232 | 7 SHIM PACK (INCLUDES 8-SHIMS) | 4 | |
| 9D0630 | 8 CAP-DUST | 1 | |
| 9D9438 | 9 WASHER (21X111X10-MM THK) | 6 | |
| 9M0164 | 10 CLAMP-HOSE | 1 | |
| 9M7958 | 11 CLAMP-HOSE | 1 | |
| 1050381 | 12 BLOCK | 1 | |
| 1162041 | 13 GUARD | 1 | |
| 1249325 | 14 SENSOR GP-FUEL LEVEL | 1 | |
| 1366202 | 15 BREATHER AS (FUEL TANK) | 1 | |
| 1452817 | 16 HOSE AS | 1 | |
| 1513177 | 17 TANK AS-FUEL | 1 | |
| 1516225 | 18 SPACER (50-MM THK) | 1 | |
| 2669923 | 19 BRACKET AS | 1 | |
| 1488373 | 20 ELBOW AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C3364 | ELBOW | 1 | |
| 1D4620 | 21 BOLT (3/4-10X7-IN) | 2 | |
| 1D4621 | 22 BOLT (3/4-10X7.5-IN) | 1 | |
| 1K6870 | 23 LOCKNUT (3/4-10-THD) | 3 | |
| 3008495 | 24 RECEIVER (FAST FILL FUEL) | 1 | |
| 4L6454 | 25 BOLT (3/8-16X1-IN) | 11 | |
| 5P6652 | 26 WASHER (20X44.5X6-MM THK) | 6 | |
| 5P6712 | 27 BOLT-LOCKING (3/4-10X3-IN) | 4 | |
| 5P8248 | 28 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 6V5051 | 29 SEAL-O-RING | 1 | |
| 6V8801 | 30 NUT (3/8-16-THD) | 5 | |
| 7X0582 | 31 WASHER-HARD (20X44.5X6-MM THK) | 6 | |
| 8T2501 | 32 BOLT (3/8-16X2-IN) | 4 | |
| 8T2561 | 33 WASHER-HARD (10.5X28.5X5-MM THK) | 5 | |
| 8T4896 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 8T9101 | 35 BOLT (3/8-16X2.75-IN) | 2 | |
| 9X8885 | 36 BOLT (3/4-10X2.25-IN) | 6 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4956 | 38 BOLT (M12X1.75X35-MM) | 6 | |
| 2801065 | 39 PLATE AS | 3 | |
| 5T8645 | KIT-VENT (FUEL TANK)(ALUMINUM) | 1 | |
| 2721595 | KIT-VENT (FUEL TANK)(PLASTIC) | 1 |
